ā 124 ā
MISCELLANEOUS
**************
14 1-773-160-11 WIRE (FLAT TYPE) (21 CORE)
15 1-769-947-11 WIRE (FLAT TYPE) (11 CORE)
64 1-777-869-11 WIRE (FLAT TYPE) (10 CORE)
65 1-777-936-11 WIRE (FLAT TYPE) (5 CORE)
66 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
74 1-769-909-11 WIRE (FLAT TYPE) (9 CORE)
104 1-777-870-11 WIRE (FLAT TYPE) (19 CORE)
106 1-233-545-11 ENCAPSULATED COMPONENT
(GR8:E2, EA4, MX, TH, AUS)
106 1-233-546-11 ENCAPSULATED COMPONENT
(GR8:E3, EA3, HK, IA, MY, SAF, SP, TW)
108 1-751-086-11 WIRE (FLAT TYPE) (13 CORE)
(GR8:E2, EA4, MX, TH, AUS)
108 1-773-012-11 WIRE (FLAT TYPE) (15 CORE) (GR8: E3, EA3,
HK, IA, MY, SAF, SP, TW, JE,/ RX90)
! 113 1-751-326-31 CORD, POWER (TH)
! 115 1-777-462-11 CORD, POWER (E, IA, MX, JE)
! 116 1-569-007-11 ADAPTOR, CONVERSION 2P (E3, IA, JE)
! 117 1-569-008-11 ADAPTOR, CONVERSION 2P (EA3, SP, TW)
! 118 1-575-651-11 CORD, POWER (AEP, AED, EE, CIS, G,
EA3, EA4, HK, MY, SAF, SP, TW)
! 119 1-690-608-11 CORD, POWER (AUS)
! 120 1-696-570-21 CORD, POWER (UK)
! 121 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
257 1-452-538-11 MAGNET
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-01 OPTICAL PICK-UP KSS-213D/ Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/ PB/ ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY SPINDLE
M102 X-4917-504-1 MOTOR ASSY SLED
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLED)
M901 1-698-792-11 FAN, DC
S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET)
! T901 1-429-994-11 TRANSFORMER, POWER
(RX90: AEP, AED, EE, CIS, G, UK)
! T901 1-429-995-11 TRANSFORMER, POWER (GR8: E, EA4,
HK, IA, MX, SAF, SP, TH, TW, AUS, JE)
! T901 1-429-995-21 TRANSFORMER, POWER (GR8: EA3, MY)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#5 7-621-775-10 SCREW +B 2.6X4
#6 7-621-255-15 SCREW +P 2X3
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#9 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-623-921-01 RING, RETAINING, CAPSTAN
#12 7-621-775-00 SCREW +B 2.6X3
#13 7-685-872-09 SCREW +BVTT 3X8 (S)
************************************************************
ACCESSORIES
************
1-501-374-11 ANTENNA, LOOP (GR8: IA, SAF, JE)
1-501-659-11 ANTENNA (FM) (GR8: SAF)
1-501-659-41 ANTENNA (FM) (GR8: IA, JE)
3-859-545-11 MANUAL, INSTRUCTION (ENGLISH)
(GR8: IA, JE)
3-859-545-31 MANUAL, INSTRUCTION (CHINESE)
(GR8: IA, JE)
3-859-545-41 MANUAL, INSTRUCTION
(KOREAN, PORTUGUESE) (GR8: JE)
4-979-371-01 COVER, BATTERY (for RM-SD80)
8-917-582-90 REMOCON, SONY RM-SD80//M SET
(GR8: IA, SAF, JE)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
HCD-GR8/RX90
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
