17
HCD-M10
3-10. HOLDER SECTION
3-9. CD MECHANISM DECK
4
CD mechanism deck
2
Two hooks
1
Screw (+BVTT3X6)
3
1
Tension spring (holder)
5
Holder section
2
Hoo
k
4
3
