Sony HCD-MD5 - Page 8

– 8 –
BRACKET (MAIN) SECTION
3 cover (FFC)
4 flat wire (21 core)
(CN807)
5 three screws
(BV3
× 8)
1 three screws
(BV3
× 8)
2 supplied OPT cap
1 four screws
(BV3
× 8)
5 three screws
(BV3
× 8)
6 bracket (MAIN)
section
SHIELD CASE (MD)
1 eight screws
(BV3
× 8)
2 shield case
(MD)
1 two screws
(BV3
× 8)
