– 9 –
CD MECHANISM
2
CD mechanism
1
two boss
MD MECHANISM SECTION
4
MD mechanism
section
1
connector
(CN101)
2
screw
(BV3
×
8)
3
cover (MDM)
(AEP, UK, German)
2
three screws
(BV3
×
8)
