– 136 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C192 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C193 1-164-346-11 CERAMIC CHIP 1uF 16V
C194 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
< CONNECTOR >
CN101 1-766-508-11 CONNECTOR, FFC/FPC (ZIF) 22P
CN102 1-766-510-21 CONNECTOR, FFC/FPC 30P
CN103 1-766-509-21 CONNECTOR, FFC/FPC 18P
CN104 1-766-898-21 HOUSING, CONNECTOR (PC BOARD) 4P
< DIODE >
D101 8-719-988-62 DIODE 1SS355
D155 8-719-031-17 DIODE 1SS322-TE85L
D161 8-719-421-15 DIODE MA8027-L
D181 8-719-033-60 DIODE F1P2STP
D183 8-719-033-60 DIODE F1P2STP
< IC >
IC101 8-752-072-68 IC CXA1981AR
IC102 8-759-243-19 IC TC7SU04F
IC121 8-752-375-36 IC CXD2535BR
IC122 8-759-243-19 IC TC7SU04F
IC151 8-759-179-60 IC MPC17A38VMEL
IC171 8-759-504-12 IC X24C01S
IC172 8-759-149-73 IC UPC842G2
IC181 8-759-095-65 IC TC74ACT540FS
IC182 8-759-243-19 IC TC7SU04F
IC191 8-759-822-99 IC L88MS05T-FA
< COIL >
L101 1-414-234-11 INDUCTOR, FERRITE BEAD
L102 1-414-234-11 INDUCTOR, FERRITE BEAD
L103 1-414-234-11 INDUCTOR, FERRITE BEAD
L105 1-414-234-11 INDUCTOR, FERRITE BEAD
L106 1-414-234-11 INDUCTOR, FERRITE BEAD
L121 1-414-234-11 INDUCTOR, FERRITE BEAD
L122 1-412-039-51 INDUCTOR CHIP 100uH
L151 1-412-622-51 INDUCTOR 10uH
L152 1-412-622-51 INDUCTOR 10uH
L153 1-412-039-51 INDUCTOR CHIP 100uH
L154 1-412-039-51 INDUCTOR CHIP 100uH
L155 1-410-980-51 INDUCTOR CHIP 1mH
L161 1-414-234-11 INDUCTOR, FERRITE BEAD
L162 1-414-234-11 INDUCTOR, FERRITE BEAD
L195 1-233-316-21 FILTER, CHIP EMI
< TRANSISTOR >
Q101 8-729-905-12 TRANSISTOR DTA144EU
Q151 8-729-905-18 TRANSISTOR DTC144EU
Q162 8-729-101-07 TRANSISTOR 2SB798-DL
Q163 8-729-905-12 TRANSISTOR DTA144EU
Q164 8-729-924-19 TRANSISTOR DTA123JU
Q181 8-729-018-75 TRANSISTOR 2SJ278MY
Q182 8-729-017-65 TRANSISTOR 2SK1764KY
< RESISTOR >
R101 1-216-077-00 METAL CHIP 15K 5% 1/10W
R102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R103 1-216-073-00 METAL CHIP 10K 5% 1/10W
R104 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R105 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R106 1-216-133-00 METAL CHIP 3.3M 5% 1/10W
R107 1-216-113-00 METAL CHIP 470K 5% 1/10W
R110 1-216-077-00 METAL CHIP 15K 5% 1/10W
R113 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R114 1-216-025-00 METAL GLAZE 100 5% 1/10W
R116 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R117 1-216-113-00 METAL CHIP 470K 5% 1/10W
R120 1-216-025-00 METAL GLAZE 100 5% 1/10W
R121 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R122 1-216-295-00 CONDUCTOR, CHIP (2012)
R123 1-216-037-00 METAL CHIP 330 5% 1/10W
R124 1-216-025-00 METAL GLAZE 100 5% 1/10W
R125 1-216-025-00 METAL GLAZE 100 5% 1/10W
R126 1-216-025-00 METAL GLAZE 100 5% 1/10W
R128 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R129 1-216-037-00 METAL CHIP 330 5% 1/10W
R130 1-216-041-00 METAL CHIP 470 5% 1/10W
R131 1-216-073-00 METAL CHIP 10K 5% 1/10W
R132 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R133 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R134 1-216-037-00 METAL CHIP 330 5% 1/10W
R135 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R136 1-216-041-00 METAL CHIP 470 5% 1/10W
R137 1-216-025-00 METAL GLAZE 100 5% 1/10W
R139 1-216-017-00 METAL GLAZE 47 5% 1/10W
R140 1-216-017-00 METAL GLAZE 47 5% 1/10W
R141 1-216-295-00 CONDUCTOR, CHIP (2012)
R142 1-216-073-00 METAL CHIP 10K 5% 1/10W
R143 1-216-073-00 METAL CHIP 10K 5% 1/10W
R144 1-216-025-00 METAL GLAZE 100 5% 1/10W
R145 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R146 1-216-037-00 METAL CHIP 330 5% 1/10W
R147 1-216-025-00 METAL GLAZE 100 5% 1/10W
R148 1-216-045-00 METAL CHIP 680 5% 1/10W
R149 1-216-025-00 METAL GLAZE 100 5% 1/10W
R150 1-216-295-00 CONDUCTOR, CHIP (2012)
R151 1-216-097-00 METAL GLAZE 100K 5% 1/10W
BD (MD)
