Sony HCD-MD5 - Page 83

– 137 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R154 1-220-262-11 METAL GLAZE 680 5% 1/4W
R155 1-220-262-11 METAL GLAZE 680 5% 1/4W
R158 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R161 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R162 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R163 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R164 1-216-045-00 METAL CHIP 680 5% 1/10W
R165 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R166 1-220-250-11 METAL GLAZE 10 5% 1/2W
R167 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R169 1-219-724-11 METAL CHIP 1 1% 1/4W
R170 1-216-073-00 METAL CHIP 10K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R172 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R174 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R176 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R178 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R181 1-216-073-00 METAL CHIP 10K 5% 1/10W
R182 1-216-089-00 METAL GLAZE 47K 5% 1/10W
R183 1-216-089-00 METAL GLAZE 47K 5% 1/10W
R186 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R187 1-216-134-00 METAL CHIP 2.2 5% 1/8W
< VARIABLE RESISTOR >
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S101 1-572-467-61 SWITCH, PUSH (1 KEY) (LIMIT)
************************************************************
* 1-662-215-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CN1701 1-568-946-11 PIN, CONNECTOR 8P
CN1702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q1701 8-729-661-94 TRANSISTOR RT1N141SK-TP
< RESISTOR >
R1703 1-249-435-11 CARBON 33K 5% 1/4W
R1704 1-249-429-11 CARBON 10K 5% 1/4W
R1705 1-249-417-11 CARBON 1K 5% 1/4W
************************************************************
* 1-653-411-11 DETECTION SW BOARD
*******************
< CONNECTOR >
CN193 1-770-010-21 CONNECTOR, BOARD TO BOARD 4P
< SWITCH >
S191 1-762-149-11 SWITCH, PUSH (1 KEY) (LOAD OUT DET)
S192 1-762-149-11 SWITCH, PUSH (1 KEY) (LOAD IN DET)
S193 1-762-149-11 SWITCH, PUSH (1 KEY) (CHACKING IN DET)
************************************************************
* A-4390-907-A DIGITAL BOARD, COMPLETE
***********************
< CAPACITOR >
C202 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C206 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C207 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C212 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C213 1-126-395-11 ELECT 22uF 20% 16V
C253 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C254 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C255 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C256 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C271 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C273 1-126-395-11 ELECT 22uF 20% 16V
C274 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C275 1-163-091-00 CERAMIC CHIP 8PF 50V
C276 1-163-091-00 CERAMIC CHIP 8PF 50V
C280 1-126-204-11 ELECT CHIP 47uF 20% 16V
C281 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C282 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C284 1-163-091-00 CERAMIC CHIP 8PF 50V
C285 1-126-204-11 ELECT CHIP 47uF 20% 16V
C286 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C287 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C301 1-126-395-11 ELECT 22uF 20% 16V
C302 1-126-395-11 ELECT 22uF 20% 16V
C303 1-126-395-11 ELECT 22uF 20% 16V
C304 1-126-395-11 ELECT 22uF 20% 16V
C305 1-126-395-11 ELECT 22uF 20% 16V
C306 1-126-395-11 ELECT 22uF 20% 16V
C307 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C308 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C309 1-126-204-11 ELECT CHIP 47uF 20% 16V
C310 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C311 1-124-779-00 ELECT CHIP 10uF 20% 16V
DIGITALDETECTION SWCONNECTORBD (MD)
