Sony HCD-MD5 - Page 84

– 138 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C312 1-164-346-11 CERAMIC CHIP 1uF 16V
C313 1-126-204-11 ELECT CHIP 47uF 20% 16V
C314 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C315 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C316 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C317 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C318 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C320 1-126-204-11 ELECT CHIP 47uF 20% 16V
C321 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C323 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C344 1-126-395-11 ELECT 22uF 20% 16V
C361 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C362 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C363 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C364 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C365 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C366 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C431 1-164-346-11 CERAMIC CHIP 1uF 16V
C471 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C472 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C474 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C475 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C477 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C480 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C481 1-126-204-11 ELECT CHIP 47uF 20% 16V
C482 1-126-204-11 ELECT CHIP 47uF 20% 16V
C483 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1001 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1002 1-216-295-00 CONDUCTOR, CHIP (2012)
C1003 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1004 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1005 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C1006 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C1009 1-163-025-11 CERAMIC CHIP 0.001uF 50V
< CONNECTOR >
CN202 1-774-031-21 CONNECTOR, FFC/FPC 30P
CN221 1-774-030-21 CONNECTOR, FFC/FPC 18P
CN223 1-770-706-11 CONNECTOR, FFC/FPC 23P
CN251 1-774-180-11 PIN, CONNECTOR (PC BOARD) 6P
CN281 1-774-863-11 PIN, CONNECTOR (PC BOARD) 8P
< DIODE >
D401 8-719-016-74 DIODE 1SS352 (suffix No. -13)
D401 8-719-800-76 DIODE 1SS226 (suffix No. -14)
< FERRITE BEAD >
FB272 1-550-907-21 BEAD, FERRITE (CHIP)
FB274 1-216-295-00 CONDUCTOR, CHIP (2012)
FB471 1-216-295-00 CONDUCTOR, CHIP (2012)
< IC >
IC201 8-759-394-99 IC M37610MD-068FP
IC271 8-752-371-17 IC CXD2536R
IC272 8-759-382-10 IC M5M44400BJ-7L2
IC301 8-759-636-55 IC M5218AFP
IC302 8-759-636-55 IC M5218AFP
IC303 8-759-429-16 IC AK4506-VS-E1
IC342 8-759-636-55 IC M5218AFP
IC431 8-759-040-83 IC BA6287F
IC480 8-759-032-23 IC MC74HC74AF
< COIL >
L221 1-550-907-21 BEAD, FERRITE (CHIP)
L301 1-216-295-00 CONDUCTOR, CHIP (2012)
L480 1-550-907-21 BEAD, FERRITE (CHIP)
L481 1-216-049-00 METAL GLAZE 1K 5% 1/10W
L482 1-409-556-11 COIL, CHOKE 47uH
< TRANSISTOR >
Q201 8-729-421-19 TRANSISTOR UN2213
< RESISTOR >
R204 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R206 1-216-073-00 METAL CHIP 10K 5% 1/10W
R209 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R214 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R216 1-216-073-00 METAL CHIP 10K 5% 1/10W
R221 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R223 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R226 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R229 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R230 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R231 1-216-073-00 METAL CHIP 10K 5% 1/10W
R233 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R234 1-216-073-00 METAL CHIP 10K 5% 1/10W
R236 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R239 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R240 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R241 1-216-073-00 METAL CHIP 10K 5% 1/10W
R242 1-216-073-00 METAL CHIP 10K 5% 1/10W
DIGITAL
