– 143 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X7001 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)(AEP, G, UK)
************************************************************
* 1-662-214-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C1801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1804 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN1801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D1801 8-719-010-47 DIODE UZ-6.2BSC
D1805 8-719-987-63 DIODE 1N4148M
< IC >
IC1801 8-759-274-09 IC BA6286N
< RESISTOR >
R1801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S1801 1-762-527-11 SWITCH, ROTARY
************************************************************
* 1-662-212-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C1701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1702 1-126-964-11 ELECT 10uF 20% 50V
C1705 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN1703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN1704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D1701 8-719-010-23 DIODE UZ-3.6BSB
< IC >
IC1701 8-759-633-65 IC M54641L
< RESISTOR >
R1706 1-249-411-11 CARBON 330 5% 1/4W
R1707 1-249-401-11 CARBON 47 5% 1/4W
************************************************************
* 1-653-412-11 MOTOR BOARD
*************
< CAPACITOR >
C199 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN191 1-568-944-11 PIN, CONNECTOR 6P
CN192 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
************************************************************
* A-4390-894-A PANEL A BOARD, COMPLETE (AEP, G)
* A-4390-898-A PANEL A BOARD, COMPLETE (UK)
* A-4390-886-A PANEL A BOARD, COMPLETE (EA, HK)
* A-4390-901-A PANEL A BOARD, COMPLETE (JE)
* A-4392-034-A PANEL A BOARD, COMPLETE (MY, SP)
***********************
* 4-932-810-11 CUSHION (FL)
* 4-984-198-01 HOLDER (FL)
< CAPACITOR >
C501 1-124-261-00 ELECT 10uF 20% 50V
C502 1-164-159-11 CERAMIC 0.1uF 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-164-159-11 CERAMIC 0.1uF 50V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-164-159-11 CERAMIC 0.1uF 50V
C509 1-164-159-11 CERAMIC 0.1uF 50V
C510 1-126-163-11 ELECT 4.7uF 20% 50V
C511 1-136-153-00 FILM 0.01uF 5% 50V
C519 1-126-933-11 ELECT 100uF 20% 10V
C520 1-162-306-11 CERAMIC 0.01uF 30% 16V
C522 1-162-306-11 CERAMIC 0.01uF 30% 16V
C524 1-162-306-11 CERAMIC 0.01uF 30% 16V
C527 1-162-306-11 CERAMIC 0.01uF 30% 16V
C528 1-162-294-31 CERAMIC 0.001uF 10% 50V
C529 1-162-294-31 CERAMIC 0.001uF 10% 50V
C530 1-162-294-31 CERAMIC 0.001uF 10% 50V
C531 1-162-294-31 CERAMIC 0.001uF 10% 50V
C532 1-162-290-31 CERAMIC 470PF 10% 50V
C533 1-162-290-31 CERAMIC 470PF 10% 50V
C534 1-162-290-31 CERAMIC 470PF 10% 50V
C535 1-162-290-31 CERAMIC 470PF 10% 50V
C536 1-162-290-31 CERAMIC 470PF 10% 50V
C537 1-162-290-31 CERAMIC 470PF 10% 50V
PANEL AMOTORMOTOR (TURN)MOTOR (SLIDE)
