Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C538 1-162-290-31 CERAMIC 470PF 10% 50V
C539 1-162-290-31 CERAMIC 470PF 10% 50V
C540 1-162-290-31 CERAMIC 470PF 10% 50V
C541 1-162-290-31 CERAMIC 470PF 10% 50V
C542 1-162-290-31 CERAMIC 470PF 10% 50V
C543 1-162-290-31 CERAMIC 470PF 10% 50V
C544 1-162-290-31 CERAMIC 470PF 10% 50V
< CONNECTOR >
CN506 1-778-349-11 CONNECTOR, BOARD TO BOARD 8P
CN507 1-778-350-11 CONNECTOR, BOARD TO BOARD 10P
< LED >
D511 8-719-046-44 LED SEL5221S (MULTI JOG TOP)
D512 8-719-313-48 LED SEL6210S-TH12 (ENTER/YES)
< FLUORESCENT INDICATOR TUBE >
FL501 1-517-582-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC502 8-759-297-23 IC M66004M8FP
IC503 8-759-297-23 IC M66004M8FP
IC504 8-759-339-53 IC GP1U28XB
< COIL >
L502 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q501 8-729-661-98 TRANSISTOR RT1P141SK-TP
Q503 8-729-661-98 TRANSISTOR RT1P141SK-TP
Q514 8-729-661-94 TRANSISTOR RT1N141SK-TP
Q515 8-729-661-94 TRANSISTOR RT1N141SK-TP
Q516 8-729-661-94 TRANSISTOR RT1N141SK-TP
Q517 8-729-661-94 TRANSISTOR RT1N141SK-TP
< RESISTOR >
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-441-11 CARBON 100K 5% 1/4W
R545 1-249-429-11 CARBON 10K 5% 1/4W
R546 1-249-429-11 CARBON 10K 5% 1/4W
R547 1-249-429-11 CARBON 10K 5% 1/4W
R548 1-249-429-11 CARBON 10K 5% 1/4W
R563 1-249-441-11 CARBON 100K 5% 1/4W
R565 1-249-441-11 CARBON 100K 5% 1/4W
R568 1-249-441-11 CARBON 100K 5% 1/4W
R570 1-249-441-11 CARBON 100K 5% 1/4W
R575 1-249-409-11 CARBON 220 5% 1/4W
R576 1-249-409-11 CARBON 220 5% 1/4W
< SWITCH >
S551 1-467-938-11 ENCODER, ROTARY (+ = MULTI JOG + -,
-TUNING/CURSOR +)
S552 1-473-403-11 ENCODER, ROTARY (+ VOLUME -)
************************************************************
* A-4390-895-A PANEL B BOARD, COMPLETE (AEP)
* A-4392-029-A PANEL B BOARD, COMPLETE (G)
* A-4390-899-A PANEL B BOARD, COMPLETE (UK)
* A-4392-035-A PANEL B BOARD, COMPLETE (MY, SP)
* A-4390-902-A PANEL B BOARD, COMPLETE (EA, HK)
* A-4392-026-A PANEL B BOARD, COMPLETE (JE)
***********************
< CAPACITOR >
C507 1-126-157-11 ELECT 10uF 20% 16V
C508 1-164-159-11 CERAMIC 0.1uF 50V
C512 1-162-292-31 CERAMIC 680PF 10% 50V
C513 1-162-292-31 CERAMIC 680PF 10% 50V
C514 1-162-292-31 CERAMIC 680PF 10% 50V
C515 1-162-292-31 CERAMIC 680PF 10% 50V
C516 1-164-027-11 CERAMIC 22PF 5% 50V
C517 1-164-026-11 CERAMIC 20PF 5% 50V
C518 1-104-905-11 CAPACITOR 0.22F 5.5V
C521 1-164-159-11 CERAMIC 0.1uF 50V
C523 1-164-159-11 CERAMIC 0.1uF 50V
C525 1-162-306-11 CERAMIC 0.01uF 30% 16V
C526 1-164-159-11 CERAMIC 0.1uF 50V
C551 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN501 1-774-288-11 CONNECTOR, FFC/FPC 22P
CN503 1-778-449-11 CONNECTOR, FFC/FPC 19P
CN504 1-778-345-11 CONNECTOR, BOARD TO BOARD 8P
CN505 1-778-346-11 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D501 8-719-046-39 LED SEL5821A-TH15 (GROOVE)
D502 8-719-046-44 LED SEL5221S (DBFB)
D503 8-719-046-46 LED SEL5221S-TH8F
(DISC SLOT INDICATOR(MD))
D508 8-719-052-21 LED SEL58420C-TH8C (DISC 1)
D509 8-719-052-21 LED SEL58420C-TH8C (DISC 2)
D510 8-719-052-21 LED SEL58420C-TH8C (DISC 3)
D513 8-719-046-44 LED SEL5221S (– TUNING/CURSOR +)
D515 8-719-987-63 DIODE 1N4148M
