Sony HCD-MD5 - Page 91

– 145 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D516 8-719-987-63 DIODE 1N4148M
D518 8-719-987-63 DIODE 1N4148M
D519 8-719-987-63 DIODE 1N4148M
D520 8-719-010-48 DIODE UZ-6.8BS
D521 8-719-200-82 DIODE 11ES2
D551 8-719-057-28 LED SML78420-TP4 (DISC 1)
D552 8-719-057-28 LED SML78420-TP4 (DISC 2)
D553 8-719-057-28 LED SML78420-TP4 (DISC 3)
D554 8-719-046-39 LED SEL5821A-TH15 (GROOVE)
< IC >
IC501 8-759-441-75 IC uPD78058GC-411-3B9
IC505 8-759-165-82 IC PST600E-T
IC506 8-759-434-66 IC TD62506F-TP
< COIL >
L501 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q502 8-729-620-05 TRANSISTOR 2SC2603-EF
Q507 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R500 1-249-437-11 CARBON 47K 5% 1/4W
R501 1-249-401-11 CARBON 47 5% 1/4W
R502 1-249-403-11 CARBON 68 5% 1/4W
R503 1-249-403-11 CARBON 68 5% 1/4W
R504 1-247-807-31 CARBON 100 5% 1/4W
R505 1-249-407-11 CARBON 150 5% 1/4W
R506 1-249-409-11 CARBON 220 5% 1/4W
R507 1-249-411-11 CARBON 330 5% 1/4W
R508 1-249-411-11 CARBON 330 5% 1/4W
R509 1-249-413-11 CARBON 470 5% 1/4W
R510 1-249-415-11 CARBON 680 5% 1/4W
R511 1-249-417-11 CARBON 1K 5% 1/4W
R512 1-249-419-11 CARBON 1.5K 5% 1/4W
R513 1-249-421-11 CARBON 2.2K 5% 1/4W
R514 1-247-843-11 CARBON 3.3K 5% 1/4W
R517 1-249-401-11 CARBON 47 5% 1/4W
R519 1-249-427-11 CARBON 6.8K 5% 1/4W
R520 1-247-843-11 CARBON 3.3K 5% 1/4W
R521 1-249-421-11 CARBON 2.2K 5% 1/4W
R522 1-249-419-11 CARBON 1.5K 5% 1/4W
R523 1-249-417-11 CARBON 1K 5% 1/4W
R524 1-249-415-11 CARBON 680 5% 1/4W
R525 1-249-413-11 CARBON 470 5% 1/4W
R526 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK, JE)
R527 1-249-429-11 CARBON 10K 5% 1/4W
(G, JE)
R528 1-249-429-11 CARBON 10K 5% 1/4W
(MY, SP, EA, HK, JE)
R530 1-249-411-11 CARBON 330 5% 1/4W
R531 1-249-411-11 CARBON 330 5% 1/4W
R533 1-249-409-11 CARBON 220 5% 1/4W
R534 1-249-407-11 CARBON 150 5% 1/4W
R535 1-247-807-31 CARBON 100 5% 1/4W
R536 1-249-403-11 CARBON 68 5% 1/4W
R537 1-249-403-11 CARBON 68 5% 1/4W
R538 1-249-403-11 CARBON 68 5% 1/4W
R539 1-249-401-11 CARBON 47 5% 1/4W
R540 1-249-419-11 CARBON 1.5K 5% 1/4W
R541 1-249-419-11 CARBON 1.5K 5% 1/4W
R542 1-249-413-11 CARBON 470 5% 1/4W
R543 1-249-419-11 CARBON 1.5K 5% 1/4W
R544 1-249-409-11 CARBON 220 5% 1/4W
R551 1-249-429-11 CARBON 10K 5% 1/4W
R559 1-249-433-11 CARBON 22K 5% 1/4W
R560 1-249-429-11 CARBON 10K 5% 1/4W
R561 1-249-425-11 CARBON 4.7K 5% 1/4W
R562 1-249-393-11 CARBON 10 5% 1/4W
R564 1-249-437-11 CARBON 47K 5% 1/4W
R566 1-249-403-11 CARBON 68 5% 1/4W
R567 1-249-429-11 CARBON 10K 5% 1/4W
R569 1-249-429-11 CARBON 10K 5% 1/4W
R571 1-249-441-11 CARBON 100K 5% 1/4W
R573 1-249-409-11 CARBON 220 5% 1/4W
R574 1-249-403-11 CARBON 68 5% 1/4W
R580 1-249-403-11 CARBON 68 5% 1/4W
R581 1-249-403-11 CARBON 68 5% 1/4W
R582 1-249-403-11 CARBON 68 5% 1/4W
R583 1-249-403-11 CARBON 68 5% 1/4W
R584 1-247-807-31 CARBON 100 5% 1/4W
R585 1-247-807-31 CARBON 100 5% 1/4W
R586 1-247-807-31 CARBON 100 5% 1/4W
R587 1-247-807-31 CARBON 100 5% 1/4W
R590 1-247-807-31 CARBON 100 5% 1/4W
R593 1-247-807-31 CARBON 100 5% 1/4W
R594 1-247-807-31 CARBON 100 5% 1/4W
R595 1-247-807-31 CARBON 100 5% 1/4W
R596 1-247-807-31 CARBON 100 5% 1/4W
R597 1-247-807-31 CARBON 100 5% 1/4W
R598 1-247-807-31 CARBON 100 5% 1/4W
R599 1-247-807-31 CARBON 100 5% 1/4W
R600 1-247-807-31 CARBON 100 5% 1/4W
R606 1-247-807-31 CARBON 100 5% 1/4W
(AEP, G, UK)
R607 1-247-807-31 CARBON 100 5% 1/4W
PANEL B
