Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
(AEP, G, UK)
R609 1-247-807-31 CARBON 100 5% 1/4W
R610 1-247-807-31 CARBON 100 5% 1/4W
R611 1-247-807-31 CARBON 100 5% 1/4W
R612 1-247-807-31 CARBON 100 5% 1/4W
R613 1-247-807-31 CARBON 100 5% 1/4W
R615 1-247-807-31 CARBON 100 5% 1/4W
R616 1-247-807-31 CARBON 100 5% 1/4W
R617 1-247-807-31 CARBON 100 5% 1/4W
R618 1-247-807-31 CARBON 100 5% 1/4W
R619 1-247-807-31 CARBON 100 5% 1/4W
R620 1-247-807-31 CARBON 100 5% 1/4W
R621 1-247-807-31 CARBON 100 5% 1/4W
R623 1-249-429-11 CARBON 10K 5% 1/4W
R624 1-249-429-11 CARBON 10K 5% 1/4W
R625 1-249-429-11 CARBON 10K 5% 1/4W
R626 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S501 1-571-760-11 SWITCH, KEY BOARD (6 (MD))
S502 1-571-760-11 SWITCH, KEY BOARD (CD SYNC)
S503 1-571-760-11 SWITCH, KEY BOARD (r REC)
S504 1-571-760-11 SWITCH, KEY BOARD (PRESET EQ)
S505 1-571-760-11 SWITCH, KEY BOARD (CHARACTER)
S506 1-571-760-11 SWITCH, KEY BOARD (ENTER/YES)
S507 1-571-760-11 SWITCH, KEY BOARD (0)
S508 1-554-303-21 SWITCH, TACTILE ())
S509 1-571-760-11 SWITCH, KEY BOARD (EDIT/NO)
S510 1-554-303-21 SWITCH, TACTILE (TIMER CONTROL)
S511 1-554-303-21 SWITCH, TACTILE (TIMER SET)
S512 1-554-303-21 SWITCH, TACTILE (DISPLAY)
S513 1-554-303-21 SWITCH, TACTILE (1/ALL)
S514 1-554-303-21 SWITCH, TACTILE (STEREO/MONO,REPEAT)
S515 1-554-303-21 SWITCH, TACTILE (TUNING MODE,PLAY MODE)
S516 1-571-760-11 SWITCH, KEY BOARD (POWER)
S517 1-571-760-11 SWITCH, KEY BOARD (p (MD))
S518 1-571-760-11 SWITCH, KEY BOARD (P (MD))
S519 1-571-760-11 SWITCH, KEY BOARD (( (MD))
S520 1-554-303-21 SWITCH, TACTILE (TUNER/BAND)
S521 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S522 1-554-303-21 SWITCH, TACTILE (LOOP)
S523 1-554-303-21 SWITCH, TACTILE (EX-CHANGE)
S524 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
S525 1-554-303-21 SWITCH, TACTILE (( (CD))
S526 1-554-303-21 SWITCH, TACTILE (P (CD))
S527 1-554-303-21 SWITCH, TACTILE (p (CD))
S528 1-554-303-21 SWITCH, TACTILE (6 (CD))
S529 1-571-760-11 SWITCH, KEY BOARD (DBFB)
S530 1-571-760-11 SWITCH, KEY BOARD (DISC 1)
S531 1-571-760-11 SWITCH, KEY BOARD (DISC 2)
S532 1-571-760-11 SWITCH, KEY BOARD (DISC 3)
S533 1-571-760-11 SWITCH, KEY BOARD (GROOVE)
< VIBRATOR >
X501 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
X502 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
************************************************************
* A-4390-875-A POWER BOARD, COMPLETE (AEP, G)
* A-4390-879-A POWER BOARD, COMPLETE (UK)
* A-4390-883-A POWER BOARD, COMPLETE (EA, HK, JE)
* A-4392-031-A POWER BOARD, COMPLETE (MY, SP)
***********************
* 3-309-144-21 HEAT SINK
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C120 1-124-903-11 ELECT 1uF 20% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-126-964-11 ELECT 10uF 20% 50V
C123 1-164-159-11 CERAMIC 0.1uF 50V
C124 1-110-489-11 CAPACITOR 1F 5.5V
C125 1-124-903-11 ELECT 1uF 20% 50V
C126 1-164-159-11 CERAMIC 0.1uF 50V
C127 1-126-933-11 ELECT 100uF 20% 16V
C139 1-162-306-11 CERAMIC 0.01uF 30% 16V
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C802 1-126-967-11 ELECT 47uF 20% 10V
C803 1-162-306-11 CERAMIC 0.01uF 30% 16V
C804 1-126-933-11 ELECT 100uF 20% 16V
C805 1-124-443-00 ELECT 100uF 20% 10V
C806 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, G, UK)
C807 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, G, UK)
C808 1-124-443-00 ELECT 100uF 20% 10V
C809 1-126-967-11 ELECT 47uF 20% 50V
C810 1-162-306-11 CERAMIC 0.01uF 30% 16V
C811 1-126-967-11 ELECT 47uF 20% 10V
C812 1-162-306-11 CERAMIC 0.01uF 30% 16V
C813 1-126-967-11 ELECT 47uF 20% 10V
C814 1-126-967-11 ELECT 47uF 20% 10V
C815 1-126-916-11 ELECT 1000uF 20% 6.3V
C816 1-126-964-11 ELECT 10uF 20% 50V
C817 1-126-967-11 ELECT 47uF 20% 10V
C818 1-126-967-11 ELECT 47uF 20% 10V
