Sony HCD-MD5 - Page 93

– 147 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C819 1-126-967-11 ELECT 47uF 20% 50V
C820 1-126-974-11 ELECT 3300uF 20% 50V
C821 1-126-974-11 ELECT 3300uF 20% 50V
C822 1-162-306-11 CERAMIC 0.01uF 30% 16V
C823 1-162-306-11 CERAMIC 0.01uF 30% 16V
C824 1-126-925-11 ELECT 470uF 20% 10V
C825 1-126-925-11 ELECT 470uF 20% 10V
C826 1-162-306-11 CERAMIC 0.01uF 30% 16V
C827 1-126-969-11 ELECT 220uF 20% 50V
C828 1-126-768-11 ELECT 2200uF 20% 16V
C829 1-126-967-11 ELECT 47uF 20% 10V
C830 1-126-967-11 ELECT 47uF 20% 10V
C831 1-162-306-11 CERAMIC 0.01uF 30% 16V
C832 1-126-027-11 ELECT 1000uF 20% 25V
C836 1-162-306-11 CERAMIC 0.01uF 30% 16V
C837 1-162-306-11 CERAMIC 0.01uF 30% 16V
C838 1-126-971-11 ELECT 470uF 20% 50V
C840 1-164-159-11 CERAMIC 0.1uF 50V
C841 1-164-159-11 CERAMIC 0.1uF 50V
C842 1-164-159-11 CERAMIC 0.1uF 50V
C843 1-164-159-11 CERAMIC 0.1uF 50V
C844 1-126-001-11 ELECT 3300uF 20% 10V
C845 1-124-360-00 ELECT 1000uF 20% 16V
C846 1-124-360-00 ELECT 1000uF 20% 16V
C847 1-115-364-11 ELECT 22000uF 20% 16V
C848 1-136-165-00 FILM 0.1uF 5% 50V
C849 1-136-165-00 FILM 0.1uF 5% 50V
C881 1-126-964-11 ELECT 10uF 20% 50V
C882 1-126-154-11 ELECT 47uF 20% 6.3V
C883 1-126-967-11 ELECT 47uF 20% 50V
C884 1-162-306-11 CERAMIC 0.01uF 30% 16V
C885 1-126-964-11 ELECT 10uF 20% 50V
C891 1-126-964-11 ELECT 10uF 20% 50V
C9001 1-101-005-00 CERAMIC 22000PF 50V
C9001 1-102-123-00 CERAMIC 0.0033uF 10% 50V
< CONNECTOR >
CN802 1-691-773-11 PLUG (MICRO CONNECTOR) 11P
CN803 1-691-772-11 PLUG (MICRO CONNECTOR) 10P
CN804 1-770-493-11 CONNECTOR, BOARD TO BOARD 9P
CN805 1-770-167-11 CONNECTOR, FFC/FPC 19P
CN807 1-770-649-11 CONNECTOR, FFC/FPC 21P
CN808 1-770-651-11 CONNECTOR, FFC/FPC 23P
* CN881 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D113 8-719-987-63 DIODE 1N4148M
D114 8-719-987-63 DIODE 1N4148M
D115 8-719-987-63 DIODE 1N4148M
D116 8-719-987-63 DIODE 1N4148M
D117 8-719-987-63 DIODE 1N4148M
D801 8-719-014-74 DIODE UZP-6.2B
D802 8-719-200-82 DIODE 11ES2
D803 8-719-011-16 DIODE UZ-33BSA
D804 8-719-109-98 DIODE RD6.8ES-B3
D805 8-719-010-43 DIODE UZ-5.6BSC
D806 8-719-010-47 DIODE UZ-6.2BSC
D807 8-719-200-82 DIODE 11ES2
D808 8-719-010-43 DIODE UZ-5.6BSC
D809 8-719-010-43 DIODE UZ-5.6BSC
D810 8-719-200-82 DIODE 11ES2
D811 8-719-200-82 DIODE 11ES2
D812 8-719-200-82 DIODE 11ES2
D813 8-719-028-23 DIODE D3SBA20-4101
D814 8-719-987-63 DIODE 1N4148M
D815 8-719-987-63 DIODE 1N4148M
D816 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D816 8-719-200-77 DIODE 10E2N (MY, SP)
D817 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D817 8-719-200-77 DIODE 10E2N (MY, SP)
D818 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D818 8-719-200-77 DIODE 10E2N (MY, SP)
D819 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D819 8-719-200-77 DIODE 10E2N (MY, SP)
D820 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D820 8-719-200-77 DIODE 10E2N (MY, SP)
D821 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D821 8-719-200-77 DIODE 10E2N (MY, SP)
D822 8-719-200-77 DIODE 10E2N
D823 8-719-200-77 DIODE 10E2N
D824 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D824 8-719-200-77 DIODE 10E2N (MY, SP)
D825 8-719-200-82 DIODE 11ES2 (AEP, G, UK, EA, HK, JE)
D825 8-719-200-77 DIODE 10E2N (MY, SP)
D881 8-719-987-63 DIODE 1N4148M
D883 8-719-200-82 DIODE 11ES2
D891 8-719-200-82 DIODE 11ES2
D892 8-719-010-55 DIODE UZ-7.5BSC
D893 8-719-987-63 DIODE 1N4148M
< GROUND PLATE >
* E801 4-942-204-01 PLATE, GROUND
< FUSE >
! F801 1-532-506-51 FUSE (6.3A/250V)
! F802 1-532-506-51 FUSE (6.3A/250V)
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
POWER
