Sony HCD-MD5 - Page 94

– 148 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC102 8-759-917-18 IC SN74HCU04AN
IC103 8-759-327-15 IC M62005L
IC801 8-759-231-58 IC TA7812S
IC821 8-759-290-19 IC BA3960
< COIL >
L103 1-412-473-21 INDUCTOR 0uH
< TRANSISTOR >
Q111 8-729-661-98 TRANSISTOR RT1P141SK-TP
Q113 8-729-661-94 TRANSISTOR RT1N141SK-TP
Q801 8-729-209-15 TRANSISTOR 2SD2012
Q802 8-729-018-59 TRANSISTOR 2SB1375-LC
Q803 8-729-209-15 TRANSISTOR 2SD2012
Q804 8-729-620-05 TRANSISTOR 2SC2603-EF
Q805 8-729-209-15 TRANSISTOR 2SD2012
Q806 8-729-209-15 TRANSISTOR 2SD2012
Q807 8-729-661-96 TRANSISTOR RT1N441SK-TP
Q808 8-729-141-83 TRANSISTOR 2SB1094-LK
Q809 8-729-209-15 TRANSISTOR 2SD2012
Q810 8-729-661-94 TRANSISTOR RT1N141SK-TP
Q811 8-729-620-05 TRANSISTOR 2SC2603-EF
Q812 8-729-620-05 TRANSISTOR 2SC2603-EF
Q881 8-729-620-05 TRANSISTOR 2SC2603-EF
Q882 8-729-661-98 TRANSISTOR RT1P141SK-TP
Q883 8-729-801-93 TRANSISTOR 2SD1387
Q884 8-729-620-05 TRANSISTOR 2SC2603-EF
Q891 8-729-801-93 TRANSISTOR 2SD1387
Q892 8-729-661-96 TRANSISTOR RT1N441SK-TP
Q893 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R114 1-249-417-11 CARBON 1K 5% 1/4W
R115 1-249-433-11 CARBON 22K 5% 1/4W
R116 1-249-437-11 CARBON 47K 5% 1/4W
R117 1-247-891-00 CARBON 330K 5% 1/4W
R118 1-249-417-11 CARBON 1K 5% 1/4W
R128 1-247-807-31 CARBON 100 5% 1/4W
R134 1-249-437-11 CARBON 47K 5% 1/4W
R150 1-247-895-00 CARBON 470K 5% 1/4W
R301 1-247-807-31 CARBON 100 5% 1/4W
R302 1-247-807-31 CARBON 100 5% 1/4W
R307 1-247-807-31 CARBON 100 5% 1/4W
R801 1-249-413-11 CARBON 470 5% 1/4W
R802 1-249-429-11 CARBON 10K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W
R804 1-249-429-11 CARBON 10K 5% 1/4W
R805 1-249-415-11 CARBON 680 5% 1/4W
R806 1-247-850-11 CARBON 6.2K 5% 1/4W
R807 1-249-416-11 CARBON 820 5% 1/4W
R808 1-247-843-11 CARBON 3.3K 5% 1/4W
R809 1-249-429-11 CARBON 10K 5% 1/4W
R810 1-247-843-11 CARBON 3.3K 5% 1/4W
R811 1-249-421-11 CARBON 2.2K 5% 1/4W
R812 1-249-425-11 CARBON 4.7K 5% 1/4W
R813 1-249-433-11 CARBON 22K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W
R815 1-249-413-11 CARBON 470 5% 1/4W
R816 1-249-413-11 CARBON 470 5% 1/4W
R817 1-249-413-11 CARBON 470 5% 1/4W
! R818 1-217-638-00 FUSIBLE 1.5 5% 1/4W F
! R819 1-217-642-11 FUSIBLE 6.8 5% 1/4W F
! R820 1-217-642-11 FUSIBLE 6.8 5% 1/4W F
R821 1-249-417-11 CARBON 1K 5% 1/4W
R822 1-249-417-11 CARBON 1K 5% 1/4W
! R823 1-217-642-11 FUSIBLE 6.8 5% 1/4W F
! R824 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
! R825 1-217-642-11 FUSIBLE 6.8 5% 1/4W F
! R826 1-217-637-00 FUSIBLE 1 5% 1/4W F
R831 1-247-807-31 CARBON 100 5% 1/4W
! R832 1-212-857-00 FUSIBLE 10 5% 1/4W F
R840 1-249-441-11 CARBON 100K 5% 1/4W
R841 1-249-441-11 CARBON 100K 5% 1/4W
R842 1-249-441-11 CARBON 100K 5% 1/4W
R843 1-249-441-11 CARBON 100K 5% 1/4W
R849 1-249-429-11 CARBON 10K 5% 1/4W
R881 1-249-429-11 CARBON 10K 5% 1/4W
R882 1-249-425-11 CARBON 4.7K 5% 1/4W
R883 1-249-429-11 CARBON 10K 5% 1/4W
R884 1-249-441-11 CARBON 100K 5% 1/4W
R885 1-249-417-11 CARBON 1K 5% 1/4W
R886 1-249-437-11 CARBON 47K 5% 1/4W
R887 1-249-437-11 CARBON 47K 5% 1/4W
R893 1-247-807-31 CARBON 100 5% 1/4W
R894 1-249-441-11 CARBON 100K 5% 1/4W
R895 1-249-429-11 CARBON 10K 5% 1/4W
R896 1-249-429-11 CARBON 10K 5% 1/4W
R897 1-249-421-11 CARBON 2.2K 5% 1/4W
< SWITCH >
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
POWER
