– 149 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S101 1-572-184-11 SWITCH, KEYBOARD (RESET)
************************************************************
* A-4390-896-A RELAY BOARD, COMPLETE (AEP, G)
* A-4390-900-A RELAY BOARD, COMPLETE (UK)
* A-4390-888-A RELAY BOARD, COMPLETE (EA, HK, JE)
* A-4392-036-A RELAY BOARD, COMPLETE (MY, SP)
**********************
< CAPACITOR >
C741 1-124-907-11 ELECT 10uF 20% 50V
C791 1-124-907-11 ELECT 10uF 20% 50V
C851 1-162-306-11 CERAMIC 0.01uF 30% 16V
C852 1-124-907-11 ELECT 10uF 20% 50V
C853 1-164-159-11 CERAMIC 0.1uF 50V
C854 1-164-159-11 CERAMIC 0.1uF 50V
C855 1-164-159-11 CERAMIC 0.1uF 50V
C856 1-162-290-31 CERAMIC 470PF 10% 50V
C857 1-162-290-31 CERAMIC 470PF 10% 50V
C858 1-162-290-31 CERAMIC 470PF 10% 50V
C859 1-162-290-31 CERAMIC 470PF 10% 50V
C860 1-162-286-31 CERAMIC 220PF 10% 50V
C861 1-162-290-31 CERAMIC 470PF 10% 50V
C871 1-162-306-11 CERAMIC 0.01uF 30% 16V
C872 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN851 1-770-649-11 CONNECTOR, FFC/FPC 21P
CN852 1-770-167-11 CONNECTOR, FFC/FPC 19P
* CN853 1-568-936-11 PIN, CONNECTOR 9P
* CN854 1-568-935-11 PIN, CONNECTOR 8P
< IC >
IC851 8-759-433-62 IC uPD78055GC-055-3B9
IC852 8-749-921-12 IC GP1F32T (CD DIGITAL OUT OPTICAL)
< COIL >
L851 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R741 1-249-441-11 CARBON 100K 5% 1/4W
R791 1-249-441-11 CARBON 100K 5% 1/4W
R851 1-247-807-31 CARBON 100 5% 1/4W
R852 1-247-807-31 CARBON 100 5% 1/4W
R856 1-247-807-31 CARBON 100 5% 1/4W
R857 1-247-807-31 CARBON 100 5% 1/4W
R858 1-247-807-31 CARBON 100 5% 1/4W
R859 1-247-807-31 CARBON 100 5% 1/4W
R860 1-247-807-31 CARBON 100 5% 1/4W
R861 1-247-807-31 CARBON 100 5% 1/4W
R862 1-247-807-31 CARBON 100 5% 1/4W
R867 1-247-843-11 CARBON 3.3K 5% 1/4W
R868 1-247-843-11 CARBON 3.3K 5% 1/4W
R869 1-247-843-11 CARBON 3.3K 5% 1/4W
R870 1-247-843-11 CARBON 3.3K 5% 1/4W
R871 1-249-429-11 CARBON 10K 5% 1/4W
R872 1-249-429-11 CARBON 10K 5% 1/4W
R874 1-249-429-11 CARBON 10K 5% 1/4W
R875 1-249-429-11 CARBON 10K 5% 1/4W
R876 1-249-429-11 CARBON 10K 5% 1/4W
R877 1-249-429-11 CARBON 10K 5% 1/4W
R878 1-249-429-11 CARBON 10K 5% 1/4W
R879 1-249-429-11 CARBON 10K 5% 1/4W
R880 1-249-429-11 CARBON 10K 5% 1/4W
R881 1-249-429-11 CARBON 10K 5% 1/4W
R882 1-249-429-11 CARBON 10K 5% 1/4W
R883 1-249-429-11 CARBON 10K 5% 1/4W
< VIBRATOR >
X851 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
************************************************************
* 1-662-213-11 SENSOR BOARD
*************
< IC >
IC1702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
(TABLE SENSOR)
IC1703 8-749-924-30 IC PHOTO REFLECTOR GP2S28(DISC SENSOR)
< RESISTOR >
R1701 1-249-416-11 CARBON 820 5% 1/4W
R1702 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
* A-4303-528-A TCB BOARD, COMPLETE (JE)
* A-4303-529-A TCB BOARD, COMPLETE (AEP, UK)
* A-4303-530-A TCB BOARD, COMPLETE (G)
********************
< CAPACITOR >
C1 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C5 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C6 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C7 1-101-004-00 CERAMIC 0.01uF 50V
(EXCEPT AEP, G, UK)
C8 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C9 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C10 1-163-031-11 CERAMIC CHIP 0.01uF 50V
TCBSENSORRELAY
