Sony HCD-MD5 - Page 97

– 151 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
FE1 1-233-532-11 FRONTEND (EA, MY, SP, HK)
FE1 1-233-542-11 FRONTEND (4GAND) (AEP, G, UK)
FE1 1-693-251-11 FRONTEND (JE)
FE2 1-233-514-11 ENCAPSULATED COMPONENT (AEP, UK)
FE2 1-239-260-11 ENCAPSULATED COMPONENT (G)
FE2 1-239-262-11 ENCAPSULATED COMPONENT
(EA, MY, SP, HK, JE)
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-176-03 IC LA1835
< IFT >
IFT41 1-409-636-11 TRANSFORMER,IF (CERAMIC FILTER)
< JUMPER RESISTOR >
JR1 1-216-295-00 CONDUCTOR, CHIP (2012) (G)
JR2 1-216-295-00 CONDUCTOR, CHIP (2012) (AEP, UK)
JR3 1-216-295-00 CONDUCTOR, CHIP (2012) (G)
JR6 1-216-295-00 CONDUCTOR, CHIP (2012)
(AEP, G, UK)
JR7 1-216-295-00 CONDUCTOR, CHIP (2012) (G)
JR8 1-216-295-00 CONDUCTOR, CHIP (2012) (AEP, UK)
JR9 1-216-295-00 CONDUCTOR, CHIP (2012) (AEP, UK)
JR45 1-216-295-00 CONDUCTOR, CHIP (2012)
JR46 1-216-296-00 CONDUCTOR, CHIP (3216)
JR47 1-216-295-00 CONDUCTOR, CHIP (2012)
JR48 1-216-295-00 CONDUCTOR, CHIP (2012)
JR49 1-216-296-00 CONDUCTOR, CHIP (3216)
JR50 1-216-295-00 CONDUCTOR, CHIP (2012)
(EA, MY, SP, HK, JE)
JR51 1-216-295-00 CONDUCTOR, CHIP (2012)
(AEP, UK, EA, MY, SP, HK, JE)
JR52 1-216-295-00 CONDUCTOR, CHIP (2012)
JR53 1-216-296-00 CONDUCTOR, CHIP (3216)
(AEP, UK, EA, MY, SP, HK, JE)
JR54 1-216-295-00 CONDUCTOR, CHIP (2012)
JW4 1-249-413-11 CARBON 470 5% 1/4W
(AEP, G, UK)
JW5 1-249-413-11 CARBON 470 5% 1/4W
(AEP, G, UK)
< COIL >
L1 1-410-521-11 MICROINDUCTOR 100uH
(EA, MY, SP, HK,JE)
L2 1-414-142-11 MICROINDUCTOR 1uH (AEP, G, UK)
L3 1-410-521-11 MICROINDUCTOR 100uH
L4 1-410-515-11 INDUCTOR 33uH (AEP, G, UK)
L41 1-407-500-00 MICROINDUCTOR 4.7mH (AEP, UK)
L41 1-410-119-11 MICROINDUCTOR(ELTYPE) 1mH
(EXCEPT AEP, UK)
< LOW PASS FILTER >
LPF41 1-239-845-11 FILTER,LOWPASS
LPF42 1-239-845-11 FILTER,LOWPASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q2 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q3 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q4 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q5 8-729-424-08 TRANSISTOR MUN2111T1
Q8 8-729-033-67 TRANSISTOR 2SK211-Y-TE85L
(EA, MY, SP, HK, JE)
Q9 8-729-216-22 TRANSISTOR 2SA812-M5M6
(AEP, UK, EA, MY, SP, HK, JE)
Q10 8-729-216-22 TRANSISTOR 2SA812-M5M6
(EA, MY, SP, HK, JE)
Q11 8-729-421-22 TRANSISTOR MUN2211T1 (AEP, UK)
Q12 8-729-421-22 TRANSISTOR MUN2211T1
(AEP, UK, EA, MY, SP, HK, JE)
Q13 8-729-421-22 TRANSISTOR MUN2211T1
(AEP, UK, EA, MY, SP, HK, JE)
Q14 8-729-421-22 TRANSISTOR MUN2211T1
(AEP, UK, EA, MY, SP, HK, JE)
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
TCB
