– 152 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
(AEP, UK)
R18 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(EA, MY, SP, HK, JE)
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, EA, MY, SP, HK, JE)
R20 1-216-121-00 METAL CHIP 1M 5% 1/10W
(EA, MY, SP, HK, JE)
R21 1-216-049-00 METAL CHIP 1.0K 5% 1/10W
R22 1-216-049-00 METAL CHIP 1.0K 5% 1/10W
R23 1-216-049-00 METAL CHIP 1.0K 5% 1/10W
R24 1-216-025-00 METAL CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON1K 5% 1/4W
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-00 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W
R33 1-249-425-11 CARBON 4.7K 5% 1/4W
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-00 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-00 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R42 1-216-073-00 METAL CHIP 10K 5% 1/10W
R43 1-216-042-00 METAL CHIP 510 5% 1/10W
R44 1-216-021-00 METAL CHIP 68 5% 1/10W
R45 1-247-843-11 CARBON 3.3K 5% 1/4W
R46 1-216-073-00 METAL CHIP 10K 5% 1/10W
R47 1-216-097-00 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W
R49 1-216-049-00 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R53 1-249-429-11 CARBON 10K 5% 1/4W
R54 1-249-399-11 CARBON 33 5% 1/4W
(AEP, UK, EA, MY, SP, HK, JE)
R55 1-216-162-00 METAL CHIP 33 5% 1/8W
R56 1-249-393-11 CARBON 10 5% 1/4W
R91 1-216-295-00 CONDUCTOR, CHIP (2012)(AEP, UK)
R91 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(EA, MY, SP, HK, JE)
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, EA, MY, SP, HK, JE)
R93 1-216-073-00 METAL CHIP 10K 5% 1/10W
(EA, MY, SP, HK, JE)
R94 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, EA, MY, SP, HK, JE)
< VARIABLE RESISTOR >
RV41 1-238-601-11 RES,ADJ,CARBON 22K
RV42 1-238-600-11 RES,ADJ,CARBON 10K
< COIL >
T1 1-409-505-11 COIL(ANT.SW3) (EA, MY, SP, HK, JE)
T2 1-402-960-11 COIL(OSC.SW3) (EA, MY, SP, HK, JE)
< TERMINAL >
TM1 1-537-238-21 TERMINALBOARD(ANT) (ANTENNA)
(EXCEPT AEP, G, UK)
TM1 1-537-488-11 TERMINALBOARD(ANT) (ANTENNA)
(AEP, G, UK)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR,CRYSTAL (4.5MHz)
X41 1-760-220-11 FILTER,CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER,CERAMIC (450KHz)
X43 1-577-075-11 OSCILLATOR,CERAMIC (456KHz)
************************************************************
* 1-663-500-11 THERMO BOARD
************
< CAPACITOR >
C988 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN905 1-506-468-11 PIN, CONNECTOR 3P
< IC >
IC982 8-759-947-34 IC LM35DZ
************************************************************
* 1-662-206-11 TRANSFORMER BOARD
*******************
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C991 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, G, UK)
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
TCB THERMO TRANSFORMER
