Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
! F953 1-532-465-51 FUSE, TIME LAG (3.15A/250V)
! F954 1-532-465-51 FUSE, TIME LAG (3.15A/250V)
! F955 1-532-464-51 FUSE (2.5A/250V)
! F956 1-532-464-51 FUSE (2.5A/250V)
< SWITCH >
! S951 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (MY, SP, EA, HK, JE)
< TRANSFORMER >
! T901 1-429-786-11 TRANSFORMER, POWER (AEP, G, UK)
! T901 1-429-787-11 TRANSFORMER, POWER (MY, SP, EA, HK, JE)
************************************************************
MISCELLANEOUS
**************
16 1-776-063-11 WIRE (FLAT TYPE) (22 CORE)
22 1-777-473-11 WIRE (FLAT TYPE) (19 CORE)
52 1-777-471-11 WIRE (FLAT TYPE) (18 CORE)
53 1-777-470-11 WIRE (FLAT TYPE) (30 CORE)
54 1-777-475-11 WIRE (FLAT TYPE) (23 CORE)
57 1-233-546-21 ENCAPSULATED COMPONENT, FM/AM TUNER
(EA, HK, SP, MY)
65 1-777-474-11 WIRE (FLAT TYPE) (21 CORE)
67 1-777-472-11 WIRE (FLAT TYPE) (19 CORE)
! 68 1-569-007-11 ADAPTOR, CONVERSION 2P (JE)
! 69 1-569-008-11 ADAPTOR, CONVERSION 2P (EA, SP, MY)
! 70 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
! 153 8-583-009-11 OPTICAL PICK-UP (MD) KMS-210A/J-N
255 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
* 262 1-452-879-11 MAGNET
! 305 8-848-367-11 OPTICAL PICK-UP (CD) KSS-213B/K-N
306 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNP801 1-574-805-11 CORD, POWER (AEP, G, EA, HK, SP, MY)
! CNP801 1-575-653-11 CORD, POWER (JE)
! CNP801 1-696-570-21 CORD, POWER (UK)
HR901 1-500-304-21 HEAD, OVER LIGHT
M101 A-4660-651-A MOTOR (SLED) ASSY (MD)
M101 X-4917-523-4 BASE (OUTSART) ASSY (SPINDLE) (CD)
M102 A-4660-650-A CHASSIS ASSY, BU (SPINDLE) (MD)
M102 X-4917-504-1 MOTOR ASSY (SLED) (CD)
M1701 A-4660-586-A MOTOR ASSY (TURN)
M1801 A-4660-926-A MOTOR (CDM) ASSY
M191 A-4660-646-A MOTOR (LOADING) ASSY
M901 1-698-861-11 MOTOR, DC FAN
S102 1-762-148-11 SWITCH, PUSH (2 KEY)
S851 1-473-335-11 ENCODER, ROTARY
! T901 1-429-786-11 TRANSFORMER, POWER (AEP, UK, G)
! T901 1-429-787-11 TRANSFORMER, POWER (EA, HK, SP, MY, JE)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-621-773-86 SCREW +BVTT 2.6X4 (S)
#3 7-621-770-67 SCREW +PTT 2.6X6 (S)
#4 7-621-775-20 SCREW +B 2.6X5
#5 7-685-104-19 SCREW +P 2X6 TYPE2 NON-SLIT
#6 7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
#7 7-627-852-08 SCREW,PRECISION +P 1.7X2.5
#8 7-685-105-19 TPG +P 2X8, TYPE 2, NON-SLIT
#9 7-621-775-10 SCREW +B 2.6X4
#10 7-621-255-15 SCREW +P 2X3
#11 7-685-649-79 SCREW +BVTP 3X14 TYPE2 N-S
#12 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#13 7-685-871-01 SCREW +BVTT 3X6 (S)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-473-840-11 REMOTE COMMANDER (RM-S5MD)
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM) (EA, HK, SP, MY, JE)
1-501-804-11 ANTENNA (FM) (AEP, UK, G)
3-858-047-11 MANUAL, INSTRUCTION (ENGLISH) (AEP, UK)
3-858-047-21 MANUAL, INSTRUCTION (FRENCH, SPANISH,
PORTUGUESE) (AEP)
3-858-047-31 MANUAL, INSTRUCTION (GERMAN) (AEP, G)
3-858-047-41 MANUAL, INSTRUCTION (DUTCH, ITALIAN)
(AEP)
3-858-047-51 MANUAL, INSTRUCTION (DENMARK, FINNISH,
SWEDISH) (AEP)
3-858-048-11 MANUAL, INSTRUCTION (ENGLISH)
(EA, HK, SP, MY, JE)
3-858-048-21 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(EA, SP, MY)
3-858-048-31 MANUAL, INSTRUCTION (CHINESE)
(EA, HK, SP, MY, JE)
3-858-048-41 MANUAL, INSTRUCTION (ARABIC) (EA)
3-858-048-51 MANUAL, INSTRUCTION (KOREAN,
PORTUGUESE) (JE)
4-981-643-01 COVER, BATTERY (for RM-S5MD)
* 4-985-266-01 CUSHION (DD5) (FRONT)
* 4-985-267-01 CUSHION (DD5) (REAR)
* 4-985-269-01 INDIVIDUAL CARTON (AEP, UK, G)
* 4-985-270-01 INDIVIDUAL CARTON (EA, HK, SP, MY)
* 4-985-270-11 INDIVIDUAL CARTON (JE)
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
TRANSFORMER
