Sony HCD-S300 - GENERAL INFORMATION; Front Panel and Remote Controls Overview

5
LOCATION OF PARTS AND CONTROLS
1 "/1 (POWER) button and indicator
2 DISC tray
3
remote sensor
4 A OPEN/CLOSE button
5 FUNCTION button
6 ./> PREV/NEXT/PRESET +/- button
7 Front Panel Display
SECTION 2
GENERAL
Front Panel
1 2 3 4 5 6 7 8 9 10 11
201918171615141312
Remote
8 H PLAY button
9 X PAUSE button
10 x STOP button
11 VOLUME control
12 DISPLAY button
13 BAND button
14 SOUND FIELD button
15 MUTING button
This section is extracted from
instruction manual.
16 TITLE button
17 DVD MENU button
18 O RETURN button
19 </m/M/, PUSH ENTER button
20 PHONES connector
