Sony HCD-S300 - DISASSEMBLY PROCEDURES; Component Disassembly Steps

6
SECTION 3
DISASSEMBLY
3-1. LOADING PANEL
Note: Follow the disassembly procedure in the numerical order given.
3-2. FRONT PANEL
Cam
Hole of chassis
1Turn the cam to the direction of arrow.
2Pull-out the disc tray.
3Loading panel
1Screw (KTP3x8)
2Screw (KTP3x8)
3Front panel assembly
