91
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< DIODE >
D1 8-719-058-87 DIODE KV1440TR-34 (US,AEP,UK)
D2 8-719-058-87 DIODE KV1440TR-34 (AEP,UK,SP,HK,E32,AUS)
D3 8-719-058-87 DIODE KV1440TR-34 (AEP,UK)
D4 8-719-058-87 DIODE KV1440TR-34
D5 8-719-976-30 DIODE KV1560NT
D5 8-729-930-99 TRANSISTOR 2SC2413KP (AEP,UK)
D6 8-719-914-42 DIODE DA204K-T-146
< IC >
IC1 8-759-584-39 IC LA1837M-TLM
IC2 8-759-483-40 IC LC72137M-TLM
< JUMPER RESISTOR >
JR1 1-216-295-91 SHORT 0 (AEP,UK,SP,HK,E32,AUS)
JR2 1-216-295-91 SHORT 0 (AEP,UK)
JR3 1-216-295-91 SHORT 0 (AEP,UK)
< COIL >
L1 1-419-283-11 COIL, AIR-CORE
L2 1-419-284-11 COIL, AIR-CORE
L3 1-419-069-11 COIL, AIR-CORE
L4 1-419-070-11 COIL, AIR-CORE
L5 1-419-072-11 COIL, AIR-CORE (AEP,UK)
L6 1-419-072-11 COIL, AIR-CORE
L7 1-419-073-11 COIL, AIR-CORE
< TRANSISTOR >
Q1 8-729-809-62 TRANSISTOR 2SK543-CJ5-TB
Q2 8-729-040-38 TRANSISTOR KTC3880-0-RTK
Q3 8-729-930-99 TRANSISTOR 2SC2413KP
Q4 8-729-930-99 TRANSISTOR 2SC2413KP
< RESISTOR >
R1 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP,UK)
R2 1-216-839-11 METAL CHIP 33K 5% 1/16W
(AEP,UK)
R3 1-216-097-91 RES-CHIP 100K 5% 1/10W
(AEP,UK)
R4 1-216-021-00 METAL CHIP 68 5% 1/10W
R5 1-216-025-91 RES-CHIP 100 5% 1/10W
R6 1-216-839-11 METAL CHIP 33K 5% 1/16W
R7 1-216-085-00 METAL CHIP 33K 5% 1/10W
(AEP,UK)
R8 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
R9 1-216-045-00 METAL CHIP 680 5% 1/10W
R12 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R14 1-216-833-91 RES-CHIP 10K 5% 1/16W
(US,SP,HK,E32,AUS)
R14 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(AEP,UK)
R15 1-216-833-91 RES-CHIP 10K 5% 1/16W
R16 1-216-813-11 METAL CHIP 220 5% 1/16W
R17 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
(US)
R17 1-216-819-11 METAL CHIP 680 5% 1/16W
(AEP,UK)
R22 1-216-107-00 METAL CHIP 270K 5% 1/10W
R23 1-216-809-11 METAL CHIP 100 5% 1/16W
R24 1-216-037-00 METAL CHIP 330 5% 1/10W
(US,SP,HK,E32,AUS)
R24 1-216-025-91 RES-CHIP 100 5% 1/10W
(AEP,UK)
R28 1-216-073-00 METAL CHIP 10K 5% 1/10W
R29 1-216-089-91 RES-CHIP 47K 5% 1/10W
R32 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R33 1-216-018-00 METAL CHIP 51 5% 1/10W
R34 1-216-064-00 METAL CHIP 4.3K 5% 1/10W
R35 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R36 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R37 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R38 1-216-049-91 RES-CHIP 1K 5% 1/10W
R39 1-216-049-91 RES-CHIP 1K 5% 1/10W
R40 1-202-926-91 METAL CHIP 36K 5% 1/16W
(US)
R40 1-202-926-11 RES-CHIP 36K 5% 1/16W
(AEP,UK,SP,HK,E32,AUS)
R41 1-216-077-91 RES-CHIP 15K 5% 1/10W
R42 1-216-830-91 METAL CHIP 5.6K 5% 1/10W
(US,SP,HK,E,AUS)
R42 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
(AEP,UK)
R43 1-216-025-91 RES-CHIP 100 5% 1/10W
R46 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(US,SP,HK,E32,AUS)
R46 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(AEP,UK)
R61 1-216-821-11 METAL CHIP 1K 5% 1/16W
R66 1-216-047-91 RES-CHIP 820 5% 1/10W
R67 1-216-041-00 METAL CHIP 470 5% 1/10W
R68 1-216-073-00 METAL CHIP 10K 5% 1/10W
R69 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R70 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R71 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R72 1-216-833-91 RES-CHIP 10K 5% 1/16W
R73 1-216-073-00 METAL CHIP 10K 5% 1/10W
R74 1-216-049-91 RES-CHIP 1K 5% 1/10W
R75 1-216-049-91 RES-CHIP 1K 5% 1/10W
R76 1-216-073-00 METAL CHIP 10K 5% 1/10W
R77 1-216-073-00 METAL CHIP 10K 5% 1/10W
R81 1-216-073-00 METAL CHIP 10K 5% 1/10W
R82 1-216-073-00 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T1 1-419-074-11 COIL (MW ANT)
T2 1-419-075-11 COIL (MW OSC)
T3 1-419-076-11 COIL (FM MIX)
T4 1-419-077-11 COIL (FM DET)
T6 1-419-079-11 COIL (MPX FILTER)
T7 1-419-079-11 COIL (MPX FILTER)
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
**************************************************************
TUNER
