Sony HCD-U1BT - Front Panel Assy

11
HCD-U1BT
q; front panel assy
Be careful not to cut the coaxial cable.
9
2
flexible flat cable
15core (CN103)
1 connector
(coaxial cable)
5 claw
4 claw
3 four screws
(+BVTP 3 × 8 )
6 Stretch the front panel assy in the direcution
of the arrows
A and B .
A
B
7
claw
8 claw
3-4. FRONT PANEL ASSY
