3-16. LEVER (LOADING R/L)
lever (loading R)
Align the horizontal position.
lever (loading L)
Install the
both levers so that they move symmetrically.
2
two hooks
5
two hooks
3
lever (loading L)
6
lever (loading R)
torsion spring (loading RV) torsion spring (loading LV)
1
4
