HCD-U1BT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7-3. AMP SECTION
#1
#1
#3
#3
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
not
supplied
not
supplied
not
supplied
main section
not
supplied
101
104
a
a
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
105
107
108
103
102
106
110
not supplied
109
F1
101 A-1186-658-A REG BOARD, COMPLETE
102 1-500-386-11 FILTER, CLAMP (FERRITE CORE)(AEP, UK, KR)
103 3-703-244-00 BUSHING (2104), CORD
0 104 1-769-079-41 CORD, POWER (KR)
0 104 1-769-744-11 CORD, POWER (UK)
0 104 1-830-188-11 CORD, POWER (AEP)
0 104 1-830-190-11 CORD, POWER (US, CND)
105 A-1186-861-A SW POWER BOARD, COMPLETE (AEP, UK, KR)
105 A-1186-871-A SW POWER BOARD, COMPLETE (US, CND)
106 1-400-932-11 FILTER, CLAMP
107 A-1186-858-A SMASTER BOARD, COMPLETE
108 1-833-047-21 CABLE, FLEXIBLE FLAT (19 CORE)
109 2-514-691-01 SHEET, RADIATION
110 2-685-893-01 INSULATED PLATE (POWER)
0 F1 1-576-232-51 FUSE (T5AL/250V)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-871-01 SCREW +BVTT 3X6 (S)
Note: If the wire (flat type) was replaced, fold it some as the
wire (flat type) before replacement.
