6-2. BLOCK DIAGRAM — FRONT SECTION —
IC303
REMOTE CONTROL
RECEIVER
FL301
S509-S516
BK
LAT
CLK
SI
35
34
33
32
3
38
36
37
35
IC302(1/2)
PANEL CONTROLLER
VFD_BK
VFD_LAT
VFD_CLK
VFD_DATA
94
KEY2
95
3 20 21 22 23 24 25 26 28
KEY1
LED_USB LED_USB_FUNC LED_CD_FUNC LED_TU_FUNC LED_AUDIO_IN_FUNC LED_PLAY LED_PAUSE LED_DISC LED_USB_ILLUMM
XOUT
X301
5MHz
13
XIN
15
RESET
12
I
2
C CLK
29
I
2
C DATA
GC_RESET
I
2
C CLK
I
2
C DATA
30
3
29
30
POWER KEY
SIRCS
LED STANDBY
74
4
91
IC107(2/5)
SYSTEM CONTROLLER
S507
S500-S506,
S508
Q502-Q506
Q508-Q513
LED DRIVE
D501-D505
D507-D513
D500 STANDBY
Q500
LED DRIVE
(FLUORESCENT INDICATOR TUBE)
