HCD-U1BT
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
CND : Canadian model
KR : Korean model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ANT BOARD
**********
< CAPACITOR >
C952 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
< CONNECTOR >
CN904 1-818-381-11 CONNECTOR, COAXIAL
*************************************************************
A-1134-279-A BD83S BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C102 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C103 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C104 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C105 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C107 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C108 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C109 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C110 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C111 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C112 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C113 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C201 1-128-995-21 ELECT CHIP 100uF 20% 10V
C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C203 1-128-995-21 ELECT CHIP 100uF 20% 10V
C204 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C205 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C206 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C207 1-128-995-21 ELECT CHIP 100uF 20% 10V
C208 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C210 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C213 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C214 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C215 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C217 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C218 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C219 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C220 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C221 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C223 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C224 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C226 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C227 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C230 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C232 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C251 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C252 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C253 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C254 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C256 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C257 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C258 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C260 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C261 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C264 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C265 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C266 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C267 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C268 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C271 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C272 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C273 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C274 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C275 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C276 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C277 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C291 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C292 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C301 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C303 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C304 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C321 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C323 1-128-995-21 ELECT CHIP 100uF 20% 10V
C401 1-128-394-11 ELECT CHIP 220uF 20% 10V
C404 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C405 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C406 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C424 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C451 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
< CONNECTOR >
CN102 1-770-706-21 CONNECTOR, FFC/FPC 23P
CN301 1-770-425-51 CONNECTOR, FFC/FPC 16P
< IC >
IC201 8-753-246-30 IC CXD3014A-201R
IC203 6-709-050-01 IC BH18LB1WG-TR
