83
HCD-U1BT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C752 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C753 1-104-658-91 ELECT 100uF 20% 10V
C754 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C756 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C757 1-126-964-11 ELECT 10uF 20% 50V
C758 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C760 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C761 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C762 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C763 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C764 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C765 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C766 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C767 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C768 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C769 1-165-737-21 ELECT 1800uF 20% 25V
C770 1-131-704-11 FILM 1uF 5% 50V
C772 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C773 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C774 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C775 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C777 1-131-704-11 FILM 1uF 5% 50V
C778 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C779 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C780 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C781 1-126-964-11 ELECT 10uF 20% 50V
C783 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C784 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C785 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C786 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C787 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C788 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C790 1-126-933-11 ELECT 100uF 20% 16V
C791 1-136-497-81 FILM 0.1uF 5% 50V
C794 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C796 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C797 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C798 1-126-964-11 ELECT 10uF 20% 50V
C799 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C804 1-163-205-00 CERAMIC CHIP 0.001uF 10% 50V
C806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C810 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C831 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C832 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C844 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C845 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C846 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C847 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C850 1-127-876-11 CERAMIC 0.01uF 10% 50V
(US, CND, KR)
< CONNECTOR >
CN700 1-784-780-11 CONNECTOR, FFC 19P
CN702 1-819-130-11 PIN, CONNECTOR 2P
CN703 1-819-130-11 PIN, CONNECTOR 2P
CN704 1-819-132-11 PIN, CONNECTOR 4P
CN705 1-815-443-11 PIN, CONNECTOR (PWB) 2P
< DIODE >
D701 6-501-193-01 DIODE 1SS355WTE-17
D702 6-501-193-01 DIODE 1SS355WTE-17
< EARTH TERMINAL >
EP701 1-537-771-21 TERMINAL BOARD, GROUND
EP702 1-537-771-21 TERMINAL BOARD, GROUND
EP703 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC701 6-707-608-01 IC PCM1803DBR
IC702 6-708-637-01 IC NJM2871BF33-TE2
IC703 6-701-261-01 IC MC74VHC74DTR2
IC704 6-707-956-01 IC NJM2871BF18-TE2
IC705 6-705-979-01 IC CXD9788AR
IC707 6-707-629-01 IC CXD9845M
IC709 6-701-189-01 IC MC74VHC1GU04DFT1
< COIL >
L701 1-469-967-21 INDUCTOR 10uH
L702 1-469-967-21 INDUCTOR 10uH
L703 1-469-967-21 INDUCTOR 10uH
L704 1-469-967-21 INDUCTOR 10uH
L705 1-412-939-11 INDUCTOR 1uH
L710 1-456-680-11 INDUCTOR 10uH
L711 1-456-680-11 INDUCTOR 10uH
L760 1-456-680-11 INDUCTOR 10uH
L761 1-456-680-11 INDUCTOR 10uH
< TRANSISTOR >
Q701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q702 8-729-600-22 TRANSISTOR 2SA1235-F
Q703 8-729-600-22 TRANSISTOR 2SA1235-F
Q752 8-729-600-22 TRANSISTOR 2SA1235-F
Q753 8-729-600-22 TRANSISTOR 2SA1235-F
< RESISTOR >
R701 1-216-809-11 METAL CHIP 100 5% 1/10W
R706 1-216-809-11 METAL CHIP 100 5% 1/10W
R707 1-216-798-11 METAL CHIP 12 5% 1/10W
R708 1-216-798-11 METAL CHIP 12 5% 1/10W
R709 1-216-798-11 METAL CHIP 12 5% 1/10W
R710 1-216-798-11 METAL CHIP 12 5% 1/10W
R711 1-216-809-11 METAL CHIP 100 5% 1/10W
R712 1-216-809-11 METAL CHIP 100 5% 1/10W
R713 1-216-809-11 METAL CHIP 100 5% 1/10W
R714 1-216-809-11 METAL CHIP 100 5% 1/10W
R718 1-216-833-11 METAL CHIP 10K 5% 1/10W
R719 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R720 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R721 1-216-833-11 METAL CHIP 10K 5% 1/10W
R722 1-216-841-11 METAL CHIP 47K 5% 1/10W
R724 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R725 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R726 1-216-849-11 METAL CHIP 220K 5% 1/10W
R727 1-216-845-11 METAL CHIP 100K 5% 1/10W
