Sony HCD-U1BT - Page 56

56
HCD-U1BT
– PANEL Board –
IC304 SN74LV123ANSR
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
R
R
1A
1B
1CLR
1Q
2Q
2CEXT
2REXT/CEXT
GND
Vcc
1REXT/CEXT
1CEXT
1Q
2Q
2CLR
2B
2A
_
_
_
_
1
2
3
4
5
EN
GND
FLG
OUT
IN
CURRENT
LIMIT
GATE
CONTROL
UVLO
THERMAL
SHUTDOWN
FLAG
DELAY
– USB Board –
IC1 R5520H001A-T1-FB
