65
HCD-U1BT
Pin No. Pin Name I/O Description
51 to 61 A19 to A9 — Not used (Open)
62 VCC — Power supply terminal (+3.3V)
63 A8 — Not used (Open)
64 VSS — Ground terminal
65 to 72 A7 to A0 — Not used (Open)
73 to 88 D15 to D0 — Not used (Open)
89 to 92 NC — Not used (Open)
93 SPEC IN I Setting terminal for the model and destination, Not used (Ground)
94 KEY2 I Front panel key input terminal (A/D output)
95 KEY1 I Front panel key input terminal (A/D input)
96 AVSS — Ground terminal
97 KEY0 I Key input terminal, Not used (Open)
98 VREF I Reference voltage (+3.3V) input terminal
99 AVCC — Power supply terminal (+3.3V)
100 NC — Not used (Open)
