76
HCD-U1BT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R928 1-216-813-11 METAL CHIP 220 5% 1/10W
R929 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R930 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R931 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R932 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R935 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R936 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R937 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R938 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R943 1-216-841-11 METAL CHIP 47K 5% 1/10W
R944 1-216-833-11 METAL CHIP 10K 5% 1/10W
R946 1-216-841-11 METAL CHIP 47K 5% 1/10W
R947 1-216-841-11 METAL CHIP 47K 5% 1/10W
R948 1-216-841-11 METAL CHIP 47K 5% 1/10W
R949 1-216-841-11 METAL CHIP 47K 5% 1/10W
*************************************************************
1-688-337-11 DRIVER BOARD
*************
< CAPACITOR >
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
C711 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-4.7C
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S701 1-762-951-21 SWITCH, PUSH (LOADING OUT)
S702 1-762-951-21 SWITCH, PUSH (CHUCKING)
*************************************************************
A-1178-318-A HP BOARD, COMPLETE
*******************
1-833-049-21 CABLE, FLEXIBLE FLAT (9 CORE)
< CAPACITOR >
C621 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C622 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C623 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C624 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C625 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C626 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C627 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C629 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D601 6-500-848-01 DIODE MC2840-T112-1
D602 6-500-848-01 DIODE MC2840-T112-1
< EARTH TERMINAL >
* EP601 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB619 1-500-329-21 INDUCTOR, FERRITE BEAD
FB620 1-216-821-11 METAL CHIP 1K 5% 1/10W
FB621 1-500-329-21 INDUCTOR, FERRITE BEAD
FB622 1-500-329-21 INDUCTOR, FERRITE BEAD
FB623 1-500-329-21 INDUCTOR, FERRITE BEAD
< JACK >
J620 1-815-629-11 JACK (AUDIO IN)
J621 1-815-629-11 JACK (i)
< RESISTOR >
R620 1-216-821-11 METAL CHIP 1K 5% 1/10W
R621 1-216-845-11 METAL CHIP 100K 5% 1/10W
R622 1-216-845-11 METAL CHIP 100K 5% 1/10W
R623 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R624 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
A-1188-677-A MAIN BOARD, COMPLETE
*********************
1-533-233-31 FUSE HOLDER
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C103 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C104 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C106 1-128-952-31 ELECT 220uF 20% 25V
C109 1-126-937-11 ELECT 4700uF 20% 16V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-126-935-11 ELECT 470uF 20% 16V
C115 1-128-951-21 ELECT 2200uF 20% 16V
C117 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C118 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C119 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C120 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C121 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C124 1-126-916-11 ELECT 1000uF 20% 6.3V
C125 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C128 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C129 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C134 1-126-923-91 ELECT 220uF 20% 10V
C135 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C136 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C137 1-126-923-91 ELECT 220uF 20% 10V
C149 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C150 1-126-923-91 ELECT 220uF 20% 10V
