– 109 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R175 1-216-025-91 RES,CHIP 100 5% 1/10W
R176 1-216-073-00 METAL CHIP 10K 5% 1/10W
R177 1-216-073-00 METAL CHIP 10K 5% 1/10W
R178 1-216-073-00 METAL CHIP 10K 5% 1/10W
R179 1-216-025-91 RES,CHIP 100 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
**************************************************************
* 1-668-268-11 CD SW BOARD
***********
< DIODE >
D631 8-719-056-13 DIODE SML79423C-TP15 (DISC 1)
D632 8-719-056-13 DIODE SML79423C-TP15 (DISC 2)
D633 8-719-056-13 DIODE SML79423C-TP15 (DISC 3)
< JUMPER RESISTOR >
JW901 1-216-296-91 SHORT 0
JW902 1-216-295-91 SHORT 0
< TRANSISTOR >
Q613 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q614 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q615 8-729-027-60 TRANSISTOR DTC144TKA-T146
< RESISTOR >
R656 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R657 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R658 1-216-063-91 METAL CHIP 3.9K 5% 1/10W
R659 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R660 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R691 1-216-027-00 METAL CHIP 120 5% 1/10W
R692 1-216-027-00 METAL CHIP 120 5% 1/10W
R693 1-216-027-00 METAL CHIP 120 5% 1/10W
R694 1-216-027-00 METAL CHIP 120 5% 1/10W
R695 1-216-027-00 METAL CHIP 120 5% 1/10W
R696 1-216-027-00 METAL CHIP 120 5% 1/10W
< SWITCH >
S637 1-762-875-21 SWITCH, KEYBOARD (1/u)
S638 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S639 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S640 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S641 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S642 1-762-875-21 SWITCH, KEYBOARD (§)
**************************************************************
* 1-658-575-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* A-4407-476-A CONT COM BOARD, COMPLETE
*************************
< CAPACITOR >
C627 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C628 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C629 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C630 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
* CN608 1-568-862-11 SOCKET, CONNECTOR 19P
< DIODE >
D610 8-719-063-93 DIODE SLR325VC-N-T32 (ENTER/NEXT)
D612 8-719-057-97 DIODE SEL5923A-TP15 (GROOVE)
D613 8-719-063-93 DIODE SLR325VC-N-T32 (JOG)
D614 8-719-064-65 DIODE SELU5723C-TP15 (DJ MIX)
D615 8-719-064-65 DIODE SELU5723C-TP15 (DJ MIX)
D616 8-719-063-93 DIODE SLR325VC-N-T32 (NON-STOP)
D617 8-719-057-97 DIODE SEL5923A-TP15 (– 0)
D618 8-719-057-97 DIODE SEL5923A-TP15 (+ ))
D801 8-719-057-97 DIODE SEL5923A-TP15 (ON/OFF)
D802 8-719-057-97 DIODE SEL5923A-TP15 (JAM)
D803 8-719-056-13 DIODE SML79423C-TP15 (AUTO BPM)
< TRANSISTOR >
Q604 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q854 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q855 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R637 1-216-039-00 METAL CHIP 390 5% 1/10W
R638 1-216-041-00 METAL CHIP 470 5% 1/10W
R639 1-216-045-00 METAL CHIP 680 5% 1/10W
R640 1-216-047-91 RES,CHIP 820 5% 1/10W
R641 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R642 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R643 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R644 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R645 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R646 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
BD
CD SW
CONT COMCONNECTOR
