– 110 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R647 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R648 1-216-075-00 METAL CHIP 12K 5% 1/10W
R666 1-216-037-00 METAL CHIP 330 5% 1/10W
R667 1-216-029-00 METAL CHIP 150 5% 1/10W
R668 1-216-027-00 METAL CHIP 120 5% 1/10W
R669 1-216-019-00 METAL CHIP 56 5% 1/10W
R670 1-216-037-00 METAL CHIP 330 5% 1/10W
R671 1-216-031-00 METAL CHIP 180 5% 1/10W
R811 1-216-029-00 METAL CHIP 150 5% 1/10W
R812 1-216-029-00 METAL CHIP 150 5% 1/10W
R813 1-216-029-00 METAL CHIP 150 5% 1/10W
R814 1-216-029-00 METAL CHIP 150 5% 1/10W
R821 1-216-039-00 METAL CHIP 390 5% 1/10W
R822 1-216-041-00 METAL CHIP 470 5% 1/10W
R823 1-216-045-00 METAL CHIP 680 5% 1/10W
R831 1-216-039-00 METAL CHIP 390 5% 1/10W
R832 1-216-041-00 METAL CHIP 470 5% 1/10W
R833 1-216-045-00 METAL CHIP 680 5% 1/10W
< SWITCH >
S601 1-473-534-11 ENCODER, ROTARY (JOG)
S602 1-473-392-11 ENCODER, ROTARY (VOLUME)
S617 1-762-875-21 SWITCH, KEYBOARD (CD LOOP)
S618 1-762-875-21 SWITCH, KEYBOARD (CD FLASH)
S619 1-762-875-21 SWITCH, KEYBOARD (CD NON-STOP)
S621 1-762-875-21 SWITCH, KEYBOARD (– 0)
S622 1-762-875-21 SWITCH, KEYBOARD (ENTER/NEXT)
S623 1-762-875-21 SWITCH, KEYBOARD (+ ))
S624 1-762-875-21 SWITCH, KEYBOARD (DBFB)
S625 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S626 1-762-875-21 SWITCH, KEYBOARD (ACTIVE)
S627 1-762-875-21 SWITCH, KEYBOARD (SELECT)
S628 1-762-875-21 SWITCH, KEYBOARD (RETURN)
S629 1-762-875-21 SWITCH, KEYBOARD (PREV)
S630 1-762-875-21 SWITCH, KEYBOARD (NEXT)
S801 1-762-875-21 SWITCH, KEYBOARD (PAD-B)
S802 1-762-875-21 SWITCH, KEYBOARD (BEAT LEVEL)
S803 1-762-875-21 SWITCH, KEYBOARD (JAM-BEAT)
S804 1-762-875-21 SWITCH, KEYBOARD (AUTO BPM)
S805 1-762-875-21 SWITCH, KEYBOARD (PAD-A)
S806 1-762-875-21 SWITCH, KEYBOARD (ON/OFF-BEAT)
S807 1-762-875-21 SWITCH, KEYBOARD (SELECT-BEAT)
S808 1-762-875-21 SWITCH, KEYBOARD (SPEED-BEAT)
< CONNECTOR >
W601 1-775-377-61 LEAD (WITH CONNECTOR)
**************************************************************
* 1-668-269-11 DECO BOARD
**********
< DIODE >
D640 8-719-063-93 DIODE SLR325VC-N-T32 (CENTER)
D641 8-719-032-86 DIODE SEL5420E (LEFT)
D642 8-719-032-86 DIODE SEL5420E (LEFT)
D643 8-719-032-86 DIODE SEL5420E (LEFT)
D644 8-719-033-06 DIODE SEL5920A (CENTER)
D655 8-719-033-06 DIODE SEL5920A (RIGHT)
D656 8-719-033-06 DIODE SEL5920A (RIGHT)
< TRANSISTOR >
Q856 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q857 8-729-027-60 TRANSISTOR DTC144TKA-T146
< RESISTOR >
R706 1-216-019-00 METAL CHIP 56 5% 1/10W
R707 1-216-019-00 METAL CHIP 56 5% 1/10W
R708 1-216-041-00 METAL CHIP 470 5% 1/10W
R709 1-216-027-00 METAL CHIP 120 5% 1/10W
R710 1-216-027-00 METAL CHIP 120 5% 1/10W
**************************************************************
* 1-668-271-11 HP BOARD
********
< CAPACITOR >
C790 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C791 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C792 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN752 1-506-469-11 PIN, CONNECTOR 4P
< GROUND PLATE >
* EP751 1-537-738-21 TERMINAL, EARTH
< JACK >
J755 1-785-200-11 JACK (LARGE TYPE)(PHONES)
**************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-128-124-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
< CONNECTOR >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
CONT COM DECO LEAF SW
HP
