– 119 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER
C222 1-162-284-31 CERAMIC 150PF 10% 50V
C223 1-164-159-21 CERAMIC 0.1uF 50V
C224 1-128-560-11 ELECT 22uF 20% 100V
C228 1-162-284-31 CERAMIC 150PF 10% 50V
C251 1-128-582-11 ELECT 10uF 20% 100V
C252 1-162-292-31 CERAMIC 680PF 10% 50V
C253 1-162-286-21 CERAMIC 220PF 10% 50V
C254 1-126-967-11 ELECT 47uF 20% 50V
C255 1-126-967-11 ELECT 47uF 20% 50V
C256 1-128-560-11 ELECT 22uF 20% 100V
C257 1-130-493-00 MYLAR 0.068uF 5% 50V
C258 1-130-493-00 MYLAR 0.068uF 5% 50V
C301 1-126-934-11 ELECT 220uF 20% 10V
C302 1-126-934-11 ELECT 220uF 20% 10V
C303 1-126-961-11 ELECT 2.2uF 20% 50V
C311 1-126-959-11 ELECT 0.47uF 20% 50V
C331 1-126-924-11 ELECT 330uF 20% 10V
C401 1-126-963-11 ELECT 4.7uF 20% 50V
C412 1-161-494-00 CERAMIC 0.022uF 25V
C413 1-161-494-00 CERAMIC 0.022uF 25V
C414 1-161-494-00 CERAMIC 0.022uF 25V
C415 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN201 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN202 1-770-724-11 CONNECTOR, BOARD TO BOARD 9P
* CN203 1-573-128-11 PIN, CONNECTOR 5P
< DIODE >
D101 8-719-510-68 DIODE D5SBA204101
D102 8-719-028-23 DIODE D3SBA20-4101
D103 8-719-200-82 DIODE 11ES2
D104 8-719-200-82 DIODE 11ES2
D111 8-719-200-82 DIODE 11ES2
D112 8-719-200-82 DIODE 11ES2
D113 8-719-936-50 DIODE HZS33-2LTD
D114 8-719-109-89 DIODE RD5.6ESB2
D201 8-719-991-33 DIODE 1SS133T-77
D251 8-719-991-33 DIODE 1SS133T-77
D301 8-719-991-33 DIODE 1SS133T-77
D311 8-719-991-33 DIODE 1SS133T-77
D321 8-719-991-33 DIODE 1SS133T-77
D331 8-719-991-33 DIODE 1SS133T-77
D332 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D404 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D407 8-719-911-19 DIODE 1SS119
D408 8-719-911-19 DIODE 1SS119
< GROUND PLATE >
* EP101 1-537-738-21 TERMINAL, EARTH
* EP201 1-537-738-21 TERMINAL, EARTH
< IC >
IC201 8-749-921-68 IC STK-4231MK2
< TRANSISTOR >
Q111 8-729-118-01 TRANSISTOR 2SB1116-K
Q201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q301 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q302 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q303 8-729-900-36 TRANSISTOR DTC124ES
Q304 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q305 8-729-900-36 TRANSISTOR DTC124ES
Q306 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q307 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q321 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q322 8-729-900-36 TRANSISTOR DTC124ES
Q401 8-729-040-20 TRANSISTOR RT1P137L-TP
Q402 8-729-900-80 TRANSISTOR DTC114ES
Q403 8-729-040-20 TRANSISTOR RT1P137L-TP
Q407 8-729-900-80 TRANSISTOR DTC114ES
Q408 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R103 1-249-441-11 CARBON 100K 5% 1/4W
! R111 1-217-637-00 FUSIBLE 1 5% 1/4W F
R112 1-249-417-11 CARBON 1K 5% 1/4W F
R113 1-249-417-11 CARBON 1K 5% 1/4W F
R114 1-247-815-91 CARBON 220 5% 1/4W
R115 1-247-815-91 CARBON 220 5% 1/4W
R116 1-249-425-11 CARBON 4.7K 5% 1/4W F
R201 1-249-417-11 CARBON 1K 5% 1/4W F
R202 1-249-437-11 CARBON 47K 5% 1/4W
R203 1-249-412-11 CARBON 390 5% 1/4W F
R204 1-249-437-11 CARBON 47K 5% 1/4W
R205 1-260-107-11 CARBON 4.7K 5% 1/2W
R206 1-260-107-11 CARBON 4.7K 5% 1/2W
! R207 1-212-881-11 FUSIBLE 100 5% 1/4W F
R208 1-220-893-11 METAL 0.22 10% 5W
R209 1-249-417-11 CARBON 1K 5% 1/4W F
R210 1-249-431-11 CARBON 15K 5% 1/4W
R211 1-249-441-11 CARBON 100K 5% 1/4W
R212 1-260-076-11 CARBON 10 5% 1/2W
! R221 1-217-637-00 FUSIBLE 1 5% 1/4W F
R222 1-260-103-11 CARBON 2.2K 5% 1/2W
R223 1-260-103-11 CARBON 2.2K 5% 1/2W
R224 1-249-425-11 CARBON 4.7K 5% 1/4W F
R251 1-249-417-11 CARBON 1K 5% 1/4W F
R252 1-249-437-11 CARBON 47K 5% 1/4W
R253 1-249-412-11 CARBON 390 5% 1/4W F
R254 1-249-437-11 CARBON 47K 5% 1/4W
R255 1-260-107-11 CARBON 4.7K 5% 1/2W
R256 1-260-107-11 CARBON 4.7K 5% 1/2W
! R257 1-212-881-11 FUSIBLE 100 5% 1/4W F
R258 1-220-893-11 METAL 0.22 10% 5W
R259 1-249-417-11 CARBON 1K 5% 1/4W F
R260 1-249-431-11 CARBON 15K 5% 1/4W
R261 1-249-441-11 CARBON 100K 5% 1/4W
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
