– 120 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R262 1-260-076-11 CARBON 10 5% 1/2W
R271 1-260-093-11 CARBON 330 5% 1/2W
R272 1-260-093-11 CARBON 330 5% 1/2W
R273 1-260-093-11 CARBON 330 5% 1/2W
R274 1-260-093-11 CARBON 330 5% 1/2W
R301 1-249-429-11 CARBON 10K 5% 1/4W
R302 1-249-425-11 CARBON 4.7K 5% 1/4W F
R303 1-249-429-11 CARBON 10K 5% 1/4W
R304 1-249-429-11 CARBON 10K 5% 1/4W
R305 1-249-425-11 CARBON 4.7K 5% 1/4W F
R306 1-249-441-11 CARBON 100K 5% 1/4W
R308 1-247-903-00 CARBON 1M 5% 1/4W
R310 1-247-903-00 CARBON 1M 5% 1/4W
R311 1-249-441-11 CARBON 100K 5% 1/4W
R312 1-249-419-11 CARBON 1.5K 5% 1/4W F
R313 1-247-863-91 CARBON 22K 5% 1/4W
R314 1-247-863-91 CARBON 22K 5% 1/4W
R315 1-249-439-11 CARBON 68K 5% 1/4W
R316 1-249-437-11 CARBON 47K 5% 1/4W
R321 1-249-440-11 CARBON 82K 5% 1/4W
R322 1-249-441-11 CARBON 100K 5% 1/4W
R323 1-249-441-11 CARBON 100K 5% 1/4W
R331 1-247-890-11 CARBON 300K 5% 1/4W
R332 1-249-429-11 CARBON 10K 5% 1/4W
R333 1-249-431-11 CARBON 15K 5% 1/4W
! R401 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
! R402 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
! R404 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
R405 1-249-429-11 CARBON 10K 5% 1/4W
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-440-11 CARBON 82K 5% 1/4W
R409 1-249-440-11 CARBON 82K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-437-11 CARBON 47K 5% 1/4W
< RELAY >
RY401 1-755-141-11 RELAY
RY402 1-755-141-11 RELAY
RY404 1-515-920-11 RELAY (24V)
< THERMISTOR >
THP321 1-807-796-11 THERMISTOR
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-240-11 TERMINAL BOARD (CHECKER PIN)
(SURROUND SPEAKER)
**************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
* 1-668-274-11 TRANSFORMER BOARD
*******************
< CONNECTOR >
* CN501 1-564-527-11 PLUG, CONNECTOR 12P
CN502 1-774-108-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
! F501 1-532-505-31 FUSE T5AL/250V
! F504 1-532-506-31 FUSE T6.3A/250V
! F505 1-532-506-31 FUSE T6.3A/250V
< FUSE HOLDER >
FH501 1-533-233-21 HOLDER, FUSE
FH502 1-533-233-21 HOLDER, FUSE
FH507 1-533-233-21 HOLDER, FUSE
FH508 1-533-233-21 HOLDER, FUSE
FH509 1-533-233-21 HOLDER, FUSE
FH510 1-533-233-21 HOLDER, FUSE
< RESISTOR >
! R501 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R502 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R503 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R504 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< SWITCH >
! S501 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
< TRANSFORMER >
! T501 1-431-828-11 TRANSFORMER, POWER
**************************************************************
* A-4414-188-A VIDEO BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C104 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C301 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C302 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C303 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C304 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C305 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C306 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C310 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C311 1-216-295-91 SHORT 0
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
POWER SENSOR
TRANSFORMER
VIDEO
To Next Page
