5-6. PRINTED WIRING BOARD – CD Board – • See page 19 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
IC701 B-5
IC702 F-3
IC703 E-6
IC704 B-3
Q701 E-5
Q702 D-6
(Page 26)
