Sony HCD-VP1 - Printed Wiring Boards - LCD Board, HP;MIC Board, VIDEO SW Board, LOADING Board

27
27
HCD-VP1
D301 D-8
D302 D-9
D304 C-8
D314 I-5
D315 I-6
D317 B-8
D319 B-7
D323 D-8
D350 E-5
D351 F-5
D352 E-4
D353 E-3
D354 E-5
D361 F-4
D362 G-3
D651 D-1
D652 D-2
D801 F-1
D802 F-1
D812 B-2
D813 C-1
D814 A-2
D815 F-1
IC101 F-8
IC201 H-8
IC301 D-7
IC303 F-6
IC304 I-7
IC305 H-4
IC306 I-7
IC307 C-8
IC308 E-9
IC309 D-3
IC311 I-6
IC312 G-4
IC350 H-2
IC351 G-2
IC352 F-3
IC801 B-3
IC803 B-4
Q101 C-9
Q102 D-9
Q103 D-9
Q106 E-6
Q201 B-9
Q202 E-9
Q203 D-9
Q206 E-7
Q303 C-8
Q304 C-8
Q305 F-7
Q306 F-7
Q308 F-7
Q310 I-5
Q311 D-9
Q312 H-4
Q313 B-8
Q314 B-7
Q315 B-7
Q316 B-7
Q317 E-6
Q318 E-6
Q320 F-7
Q321 B-8
Q322 B-8
Q351 E-4
Q352 E-3
Q353 E-3
Q354 E-3
Q355 E-4
Q356 E-4
Q357 I-3
Q358 I-2
Q359 I-1
Q360 H-2
Q651 B-1
Q652 B-1
Q653 B-2
Q654 B-1
Q655 B-1
Q656 D-3
Q657 D-3
Q658 D-3
Q659 D-3
Q661 C-2
Q662 C-2
Q808 B-6
Ref. No. LocationRef. No. Location
• Semiconductor Location
– MAIN Board –
5-13. PRINTED WIRING BOARDS – LCD Board, HP/MIC Board, VIDEO SW Board, LOADING Board – • See page 19 for Circuit Boards Location.
M
M901
DISC TRAY
OPEN/CLOSE
S901
DISC TRAY
CLOSE DET
S902
DISC TRAY
OPEN DET
CN900
1
5
11
1-640-523-
G
LOADING BOARD
05
(Page 26)
(Page 26)
(Page 26) (Page 26)
(Page 26)
