Sony HCD-VP1 - Page 31

31
• Waveforms
– CD Board –
1 IC703 !£ (TE) (CD play mode)
2 IC703 !∞ (FE) (CD play mode)
3 IC703 !§ (RFO) (CD play mode)
4 IC701 $∞ (LRCK)
6 IC701 %∞ (RFCK)
7 IC701 ^™ (XTAI)
8 IC701 &£ (WFCK)
9 IC701 (§ (MDP) (CD play mode)
430 mVp-p
170 mVp-p
1.3 Vp-p
0.8 Vp-p
22.8 µ s
5 IC701 $¶ (BCLK)
5.1 Vp-p
470 ns
5.6 Vp-p
136 µ s
5.2 Vp-p
16.9344 MHz
5.6 Vp-p
136 µ s
2.6 Vp-p
7.6
µ s
– MAIN Board –
1 Q357, 358 collector (REC mode)
2 Q360 collector (REC mode)
3 IC801 (£ (TEX)
4 IC801 $º (XTAL1)
11.6 µ s
13.6 Vp-p
11.6 µ s
0.5 Vp-p
32.768 kHz
2.4 Vp-p
4.19 MHz
5.2 Vp-p
