IC702 BA6392FP-E2
BUFF
BUFF BUFF
BUFF
R
RF
F
1CH1 OUT F
2CH1 OUT R
3CAPA IN 1
4CH1 R IN
5CH1 F IN
6VREF IN
7VREF OUT
8GND
9CH2 F IN
10CH2 R IN
11CAPA IN 2
12CH2 OUT R
13CH2 OUT F
14GND
28 GND
27 CH4 OUT F
26 CH4 OUT R
25 VB IN
24 VS IN
23 VB IN
22 VCC
21 VCC
20 CH3 F IN
19 CH3 R IN
18 CAPA IN 3
17 CH3 OUT R
16 CH3 OUT F
15 MUTE
LEVEL
SHIFT
INTERFACE
BUFF
BUFF
BUFF
BUFF
R
F
R
F
BUFF
INTERFACE INTERFACE
FF
RR
MUTE
IC703 CXA1821M-T6
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
LD VCCVCC
PD LD ON
A LC/PD
B RFE
C RFO
D FE
VEE FE BIAS
F TE
E VC
VC
VC BUFFER
TRACKING ERROR AMP
FOCUS ERROR AMP
RF EQ AMP
APC LD AMP
RF SUMMING AMP
EI EO
VEE
VCC
VCC
VC
VC
VC
VC
VC
VC
VC
VEE
VEE
VEE
VREF
