Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
67
HCD-VX333
< CONNECTOR >
CN502 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN504 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D541 8-719-510-68 DIODE D5SBA204101
D542 8-719-210-21 DIODE 11EQS04-NTA1B
D543 8-719-210-21 DIODE 11EQS04-NTA1B
D551 8-719-991-33 DIODE 1SS133T-77
< TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH (TW)
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-96 IC STK402-120S
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q582 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q583 8-729-900-36 TRANSISTOR BA1F4M-TP
Q584 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-416-11 CARBON 820 5% 1/4W F
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0R508 1-217-156-00 METAL 0.22 20% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
0R510 1-217-156-00 METAL 0.22 20% 5W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-433-11 CARBON 22K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-429-11 CARBON 10K 5% 1/4W
R519 1-249-433-11 CARBON 22K 5% 1/4W
R520 1-249-441-11 CARBON 100K 5% 1/4W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-409-11 CARBON 220 5% 1/4W F
R524 1-247-897-11 CARBON 560K 5% 1/4W
R525 1-249-437-11 CARBON 47K 5% 1/4W
R541 1-260-115-11 CARBON 22K 5% 1/2W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-416-11 CARBON 820 5% 1/4W F
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0R558 1-217-156-00 METAL 0.22 20% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
0R560 1-217-156-00 METAL 0.22 20% 5W
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-260-115-11 CARBON 22K 5% 1/2W
0R592 1-219-591-11 FUSIBLE 0.1 5% 1/2W
0R593 1-219-119-81 FUSIBLE 0.1 5% 1/4W
************************************************************
1-681-442-11 SENSOR BOARD
*************
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR
************************************************************
1-681-445-11 SUB TRANS BOARD
****************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN2 1-568-106-11 PIN, CONNECTOR 4P (E,EA,IA,JE,MY,SP,TW)
* CN2 1-564-321-21 PIN, CONNECTOR 2P (TH)
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN903 1-785-315-11 PIN, CONNECTOR (STRAIGHT) 3P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D902 8-719-200-82 DIODE 11ES2-NTA1B
D903 8-719-200-82 DIODE 11ES2-NTA1B
D904 8-719-200-82 DIODE 11ES2-NTA1B
D905 8-719-200-82 DIODE 11ES2-NTA1B
< IC >
IC901 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
POWER SENSOR SUB TRANS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
