Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
68
HCD-VX333
SUB TRANS
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-435-828-11 TRANSFORMER, POWER
************************************************************
1-681-444-11 TRANS BOARD
************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C911 1-128-553-11 ELECT 220uF 20% 63V
C912 1-126-964-11 ELECT 10uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN915 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D911 8-719-200-82 DIODE 11ES2-NTA1B
D912 8-719-982-20 DIODE MTZJ-T-77-30B
D913 8-719-109-89 DIODE MTZJ-T-77-5.6B
< FUSE >
0F914 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (8A/250V)
0F919 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (5A/250V)
(E,EA,IA,JE,MY,SP,TW)
0F920 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (8A/250V)
< TRANSISTOR >
Q911 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
R905 1-249-429-11 CARBON 10K 5% 1/4W
0R911 1-217-637-00 FUSIBLE 1 5% 1/4W
R912 1-249-417-11 CARBON 1K 5% 1/4W F
R913 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
0R920 1-219-122-91 FUSIBLE 0.33 5% 1/4W
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (E,EA,IA,JE,MY,SP,TW)
************************************************************
A-4726-022-A VIDEO CD BOARD, COMPLETE
************************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C304 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C305 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C306 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C307 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C308 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C309 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C310 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C311 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C312 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C313 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C314 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C315 1-163-255-11 CERAMIC CHIP 150PF 5% 50V
C316 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C317 1-126-193-11 ELECT 1uF 20% 50V
C318 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C319 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C320 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C321 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C322 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C323 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C324 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C325 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C504 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C508 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C535 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C536 1-126-193-11 ELECT 1uF 20% 50V
C537 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C540 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C541 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C542 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C543 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C545 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C546 1-165-319-11 CERAMIC CHIP 0.1uF 50V
VIDEO CDTRANS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
