S MIC Chassis
2-2-3. Switching Regulator Removal
2-2-4. D Board Removal
4 Open the D board.
2 Unhook the claw.
3 Unhook the claw.
Remove the two
screws (BVTP3 x 8).
1
Remove the center
frame.
Remove the four
screws (BVTP3 x 8).
1
2
3
6
4
Remove the screw
(PSW3 x 8)
5 Remove the screw (PSW3 x 8).
Remove the power
block shield.
Shield
7 G board
Remove the
switching
regulator.
CN651
CN601
