8-2
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
* A-1135-964-A B BOARD, COMPLETE
(PVM-8042Q, 8045Q)
* A-1135-977-A B BOARD, COMPLETE
(PVM-9042QM, 9045QM)
* A-1135-981-A B BOARD, COMPLETE (PVM-9045PM)
*************************************
<BAND PASS FILTER>
BPF101 1-236-363-11 FILTER, BAND PASS
BPF102 1-236-363-11 FILTER, BAND PASS (PVM-9045PM)
BPF102 1-236-364-11 FILTER, BAND PASS
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
<CAPACITOR>
C101 1-124-589-11 ELECT 47µF 20% 16V
C102 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C103 1-126-157-11 ELECT 10µF 20% 16V
C104 1-163-031-11 CERAMIC CHIP 0.01µF 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C105 1-163-031-11 CERAMIC CHIP 0.01µF 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C106 1-104-664-11 ELECT 47µF 20% 16V
C107 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C108 1-104-664-11 ELECT 47µF 20% 16V
C109 1-104-664-11 ELECT 47µF 20% 16V
C110 1-104-666-11 ELECT 220µF 20% 16V
C111 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C112 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C113 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C114 1-104-664-11 ELECT 47µF 20% 16V
C115 1-163-031-11 CERAMIC CHIP 0.01µF 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C116 1-124-589-11 ELECT 47µF 20% 16V
C117 1-124-589-11 ELECT 47µF 20% 6.3V
C118 1-124-589-11 ELECT 47µF 20% 6.3V
C119 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C120 1-124-589-11 ELECT 47µF 20% 6.3V
C121 1-124-589-11 ELECT 47µF 20% 6.3V
C122 1-104-664-11 ELECT 47µF 20% 16V
C123 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C124 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C125 1-124-589-11 ELECT 47µF 20% 6.3V
C126 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C127 1-124-589-11 ELECT 47µF 20% 6.3V
C128 1-124-589-11 ELECT 47µF 20% 6.3V
C129 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C130 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C131 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C132 1-124-589-11 ELECT 47µF 20% 16V
C133 1-124-589-11 ELECT 47µF 20% 16V
C134 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C135 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C137 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C138 1-124-589-11 ELECT 47µF 20% 16V
C139 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C140 1-163-205-00 CERAMIC CHIP 0.001µF 5% 50V
C141 1-163-141-00 CERAMIC CHIP 0.001µF 5% 50V
C142 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C143 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C144 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C145 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C146 1-126-157-11 ELECT 10µF 20% 16V
C147 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C148 1-126-160-11 ELECT 1µF 20% 50V
C149 1-163-022-00 CERAMIC CHIP 0.012µF 10% 50V
C150 1-124-589-11 ELECT 47µF 20% 16V
C151 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C152 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C153 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C154 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C155 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C156 1-164-299-11 CERAMIC CHIP 0.22µF 10% 25V
C157 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C158 1-104-664-11 ELECT 47µF 20% 16V
C159 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C160 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C161 1-124-902-00 ELECT 0.47µF 20% 50V
C162 1-124-903-11 ELECT 1µF 20% 50V
C163 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C164 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C165 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C166 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C167 1-104-664-11 ELECT 47µF 20% 16V
C168 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C169 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C170 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C171 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C172 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C173 1-124-589-11 ELECT 47µF 20% 16V
C174 1-104-664-11 ELECT 47µF 20% 16V
C175 1-104-987-11 MYLAR 0.001µF 5% 50V
C176 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C177 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C178 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C179 1-126-160-11 ELECT 1µF 20% 50V
C180 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C181 1-124-589-11 ELECT 47µF 20% 6.3V
C182 1-124-259-11 ELECT 4.7µF 20% 16V
C183 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C184 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C185 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C186 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C187 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C188 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C189 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C190 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C192 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C193 1-124-589-11 ELECT 47µF 20% 16V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C194 1-124-589-11 ELECT 47µF 20% 16V
C195 1-124-589-11 ELECT 47µF 20% 16V
C196 1-124-589-11 ELECT 47µF 20% 16V
C197 1-124-589-11 ELECT 47µF 20% 16V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
[B]
