Sony HT-NT3 Service Manual

HT-NT3
77
Pin No. Pin Name I/O Description
151 TDVDD12 - Power supply terminal (+1.2V)
152 T0XC– O TMDS clock (negative) output to the video processor
153 T0XC+ O TMDS clock (positive) output to the video processor
154 T0X0– O TMDS data (negative) output to the video processor
155 T0X0+ O TMDS data (positive) output to the video processor
156 T0X1– O TMDS data (negative) output to the video processor
157 T0X1+ O TMDS data (positive) output to the video processor
158 T0X2– O TMDS data (negative) output to the video processor
159 T0X2+ O TMDS data (positive) output to the video processor
160 CVCC12 - Power supply terminal (+1.2V)
161 to
171
D0 to D10 I Video data input terminal Not used
172 IDCK I Input data clock signal input terminal Not used
173 IOVCC33 - Power supply terminal (+3.3V)
174 to
176
D11 to D13 I Video data input terminal Not used

Sony HT-NT3 Specifications

General

Output power	400 W
Apple docking compatibility	Not supported
HDMI in	3
Bluetooth	Yes
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Number of amplifier channels	2.1 channels
Audio decoders	Dolby Digital Plus, Dolby Dual Mono, Dolby TrueHD, DTS, DTS 96/24
Subwoofer location	Separate
Receiver included	No
Product color	Black

Weight and Dimensions

Depth	65 mm
Width	1070 mm
Height	86 mm
Soundbar weight	3100 g
Subwoofer depth	382 mm
Subwoofer width	190 mm
Subwoofer height	385 mm
Subwoofer weight	8000 g
