Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-NT3
88
C5038 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
* C5039 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5040 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5043 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5050 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5052 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5054 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5057 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5060 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5061 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C5064 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5070 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C5072 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
* C5074 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5076 1-116-724-11 CERAMIC CHIP 4.7uF 20% 6.3V
* C5077 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5078 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5079 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5084 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C5089 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
* C5091 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5092 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5104 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
* C5106 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C5108 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5109 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5110 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C5111 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C5112 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C5118 1-116-724-11 CERAMIC CHIP 4.7uF 20% 6.3V
* C5119 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5120 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5121 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C5122 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5123 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5124 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5125 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5134 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C5138 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
* C5139 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5140 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5142 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5144 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5150 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5152 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5154 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5158 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5160 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5161 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C5164 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5170 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C5172 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5174 1-116-724-11 CERAMIC CHIP 4.7uF 20% 6.3V
* C5175 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5176 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5177 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C5182 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C5184 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5190 1-118-040-1
1 CERAMIC CHIP 2.2uF 10% 16V
C5192 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5222 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C5223 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C5224 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C5226 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN301 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN401 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN501 1-573-768-21 PIN, CONNECTOR (1.5MM) (SMD) 5P
* CN502 1-819-333-11 HEADER ASSEMBLY FOR PWB 5P
CN703 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN705 1-820-112-51 CONNECTOR, FFC/FPC 9P
* CN706 1-793-152-21 CONNECTOR 11P
CN3002 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN3003 1-817-068-21 CONNECTOR 9P
CN3004 1-815-762-71 CONNECTOR, FFC/FPC 14P
CN3005 1-785-125-21 CONNECTOR 6P
CN3502 1-821-398-41 HDMI CONNECTOR (HDMI IN 2)
* CN3503 1-821-916-12 HDMI CONNECTOR (HDMI IN 3)
CN5001 1-821-398-41 HDMI CONNECTOR (HDMI IN 1 (HDCP 2.2))
CN5012 1-821-398-41 HDMI CONNECTOR (HDMI OUT (ARC HDCP 2.2))
< DIODE >
D704 6-502-967-01 DI DZ2J06200L
D3001 6-502-961-01 DI DA2J10100L
D3002 6-503-761-01 DI RB751S40, 115
D5001 6-503-735-01 DI BZT52H-C4V3
< EARTH TERMINAL >
ET301 1-780-945-11 TERMINAL, CONTACT
ET302 1-780-945-11 TERMINAL, CONTACT
ET303 1-780-945-11 TERMINAL, CONTACT
ET304 1-780-945-11 TERMINAL, CONTACT
ET305 1-780-945-11 TERMINAL, CONTACT
< FERRITE BEAD >
FB501 1-481-349-21 EMI FERRITE (SMD) (1608)
FB702 1-400-794-21 EMI FERRITE (SMD) (1608)
FB705 1-400-851-11 EMI, FERRITE (SMD) (1005)
FB707 1-218-990-81 SHORT CHIP 0 (AEP, UK, RU, AUS)
FB707 1-400-462-21 FERRITE, EMI (SMD) (1005)
(EXCEPT AEP, UK, RU, AUS)
FB708 1-400-851-11 EMI, FERRITE (SMD) (1005)
FB709 1-469-122-21 FERRITE, EMI (SMD) (1608)
FB710 1-400-462-21 FERRITE, EMI (SMD) (1005)
FB711 1-400-851-11 EMI, FERRITE (SMD) (1005)
FB712 1-400-851-11 EMI, FERRITE (SMD) (1005)
FB3002 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3501 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3504 1-216-864-11 SHORT CHIP 0
FB3505 1-216-864-11 SHORT CHIP 0
FB3508 1-469-525-91 INDUCTOR 10uH
FB3511 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB3512 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB3520 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB3521 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB3522 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB3523 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB5000 1-481-348-21 EMI FERRITE (SMD) (1608)
FB5002 1-400-580-21 FERRITE, EMI (SMD)
FB5004 1-481-348-21 EMI FERRITE (SMD) (1608)
FB5006 1-481-348-21 EMI FERRITE (SMD) (1608)
MB-1407
Ver. 1.1

Sony HT-NT3 Specifications

General

Output power	400 W
Apple docking compatibility	Not supported
HDMI in	3
Bluetooth	Yes
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Number of amplifier channels	2.1 channels
Audio decoders	Dolby Digital Plus, Dolby Dual Mono, Dolby TrueHD, DTS, DTS 96/24
Subwoofer location	Separate
Receiver included	No
Product color	Black

Weight and Dimensions

Depth	65 mm
Width	1070 mm
Height	86 mm
Soundbar weight	3100 g
Subwoofer depth	382 mm
Subwoofer width	190 mm
Subwoofer height	385 mm
Subwoofer weight	8000 g
