Sony HT-NT3 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-NT3
89
FB5008 1-400-580-21 FERRITE, EMI (SMD)
FB5010 1-481-348-21 EMI FERRITE (SMD) (1608)
< IC >
IC101 (Not supplied) IC CXD90028GB-B
@ IC102 (Not supplied) IC K4B2G1646Q-BCMA
@ IC103 (Not supplied) IC K4B2G1646Q-BCMA
IC301 (Not supplied) IC TPS542941PWPR
IC302 (Not supplied) IC TPS542941PWPR
IC303 (Not supplied) IC TPS542941PWPR
IC410 (Not supplied) IC MFI337S3959
IC502 6-720-030-01 IC TPS2065CDBVR
IC503 6-720-030-01 IC TPS2065CDBVR
IC701 6-719-070-01 IC MM3411A50URE
IC703 6-710-554-01 IC PCM1808PWR
IC704 8-759-831-52 IC TC7WH125FK
IC2001 6-721-743-01 IC TC58NVG2S0HTAI0
IC3002 6-709-888-01 IC TC7WHU04FK
IC3003 6-706-483-01 IC TC7SH02FU
IC3004 (Not supplied) IC MB9BF128SPMC-GE1
IC3005 6-713-333-01 IC PST8429UL
IC3506 6-718-773-01 IC SII9575CTUC
IC5000 6-719-062-01 IC W25X20CLSNIG
IC5001 6-721-481-01 IC SII9679CNUC
IC5009 6-719-062-01 IC W25X20CLSNIG
IC5010 (Not supplied) IC SII9678CNUC
IC5014 6-718-999-01 IC MM1839A50NRE
< JACK >
* J503 1-843-965-11 ETHERNET CONNECTOR (LAN (100))
< COIL >
L302 1-460-358-11 INDUCTOR 2.2uH
L303 1-400-789-21 INDUCTOR 2.2uH
L304 1-460-358-11 INDUCTOR 2.2uH
L305 1-400-789-21 INDUCTOR 2.2uH
L306 1-460-358-11 INDUCTOR 2.2uH
L307 1-460-358-11 INDUCTOR 2.2uH
L308 1-460-358-11 INDUCTOR 2.2uH
* L309 1-460-599-11 INDUCTOR 4.7uH
L310 1-460-358-11 INDUCTOR 2.2uH
L501 1-457-965-11 COIL,COMMON MODE CHOKE(SMD1210
L502 1-457-965-11 COIL,COMMON MODE CHOKE(SMD1210
L503 1-457-374-21 COMMOM MODE CHOKE COIL
L504 1-457-374-21 COMMOM MODE CHOKE COIL
< TRANSISTOR >
Q301 6-552-936-01 TR LTC014EUBFS8TL
Q302 6-552-936-01 TR LTC014EUBFS8TL
Q303 6-552-936-01 TR LTC014EUBFS8TL
Q304 6-552-936-01 TR LTC014EUBFS8TL
Q305 6-552-936-01 TR LTC014EUBFS8TL
Q306 6-552-936-01 TR LTC014EUBFS8TL
Q307 6-553-470-01 TR QM2401C1
Q308 6-553-470-01 TR QM2401C1
Q309 6-553-470-01 TR QM2401C1
Q310 6-553-470-01 TR QM2401C1
Q311 6-552-974-01 TR RZM001P02T2L
Q312 6-552-974-01 TR RZM001P02T2L
Q313 6-552-936-01 TR LTC014EUBFS8TL
Q314 6-553-470-01 TR QM2401C1
Q602 6-550-901-01 TR RN1302 (TE85L.F)
Q3002 6-552-936-01 TR LTC014EUBFS8TL
Q3003 6-552-936-01 TR LTC014EUBFS8TL
Q3004 6-552-936-01 TR LTC014EUBFS8TL
Q3005 6-552-892-01 TR LSCR523UBFS8TL
Q3007 6-552-941-01 TR LTC023JUBFS8TL
Q3008 6-552-941-01 TR LTC023JUBFS8TL
Q3009 6-552-936-01 TR LTC014EUBFS8TL
Q3010 6-553-470-01 TR QM2401C1
< RESISTOR >
R101 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R102 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R104 1-218-941-81 METAL CHIP 100 5% 1/16W
* R105 1-250-480-11 METAL CHIP 240 1% 1/16W
R106 1-218-941-81 METAL CHIP 100 5% 1/16W
* R107 1-250-480-11 METAL CHIP 240 1% 1/16W
R301 1-218-971-81 METAL CHIP 33K 5% 1/16W
R302 1-218-971-81 METAL CHIP 33K 5% 1/16W
R303 1-218-971-81 METAL CHIP 33K 5% 1/16W
R304 1-218-971-81 METAL CHIP 33K 5% 1/16W
R305 1-218-971-81 METAL CHIP 33K 5% 1/16W
R306 1-218-971-81 METAL CHIP 33K 5% 1/16W
R307 1-218-971-81 METAL CHIP 33K 5% 1/16W
R308 1-218-971-81 METAL CHIP 33K 5% 1/16W
R309 1-218-971-81 METAL CHIP 33K 5% 1/16W
R310 1-218-971-81 METAL CHIP 33K 5% 1/16W
R311 1-218-971-81 METAL CHIP 33K 5% 1/16W
R312 1-218-971-81 METAL CHIP 33K 5% 1/16W
R313 1-218-965-11 METAL CHIP 10K 5% 1/16W
R314 1-218-965-11 METAL CHIP 10K 5% 1/16W
R315 1-218-965-11 METAL CHIP 10K 5% 1/16W
R316 1-218-965-11 METAL CHIP 10K 5% 1/16W
R317 1-218-965-11 METAL CHIP 10K 5% 1/16W
R318 1-218-965-11 METAL CHIP 10K 5% 1/16W
R326 1-218-953-11 METAL CHIP 1K 5% 1/16W
R328 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R329 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R330 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R331 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R332 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R333 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R334 1-208-918-11 METAL CHIP 20K 0.5% 1/16W
R335 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R336 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R340 1-218-971-81 METAL CHIP 33K 5% 1/16W
R341 1-218-971-81 METAL CHIP 33K 5% 1/16W
R342 1-218-965-11 METAL CHIP 10K 5% 1/16W
R347 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R348 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R349 1-218-953-11 METAL CHIP 1K 5% 1/16W
R351 1-208-871-81 METAL CHIP 220 0.5% 1/16W
R352 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R353 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R354 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R355 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R356 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R402 1-218-965-11 METAL CHIP 10K 5% 1/16W
R408 1-218-965-11 METAL CHIP 10K 5% 1/16W
MB-1407
Note: IC 101, IC102, IC103, IC301 IC302, IC303, IC410, IC3004 and
IC5010 on the MB-1407 board cannot exchange with single.
When these parts on the MB-1407 board are damaged, ex-
change the entire mounted board.
@ Replacement of IC102 and IC103 on the MB-1407
board used in this unit requires a special tool.
Ver. 1.1

Sony HT-NT3 Specifications

General

Output power	400 W
Apple docking compatibility	Not supported
HDMI in	3
Bluetooth	Yes
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Number of amplifier channels	2.1 channels
Audio decoders	Dolby Digital Plus, Dolby Dual Mono, Dolby TrueHD, DTS, DTS 96/24
Subwoofer location	Separate
Receiver included	No
Product color	Black

Weight and Dimensions

Depth	65 mm
Width	1070 mm
Height	86 mm
Soundbar weight	3100 g
Subwoofer depth	382 mm
Subwoofer width	190 mm
Subwoofer height	385 mm
Subwoofer weight	8000 g
