5.2 Vp-p
474 ns
1.3 Vp-p
+0.25
–0.20
Approx.
500 mVp-p
Approx.
200 mVp-p
1.3 Vp-p
+0.25
–0.20
5.2 Vp-p
22.7
µ
s
5.2 Vp-p
16.9344 MHz
2.6 Vp-p
7.5
µ
s
• Waveforms
– BD BOARD –
1 IC101 @§ (RFDC) 200 mV/DIV, 500 ns/DIV
2 IC101 @¶ (TE) 200 mV/DIV, 100 µs/DIV
3 IC101 @ª (FE) 200 mV/DIV, 50 ns/DIV
4 IC101 #§ (RFAC) 200 mV/DIV, 500 ns/DIV
5 IC101 $∞ (LRCK)
6 IC101 $¶ (BCLK)
7 IC101 ^™ (XTAI)
8 IC101 (§ (MDP)
– VIDEO BOARD –
1 IC501 5 (LRCK)
2 IC501 !£ (BCLK)
3 IC502 !£ (XOUT)
4 IC502 !∞ (XIN)
5 IC502 $∞ (BUS)
