Sony KDF-46E2000 - Page 126

126
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
R6925 1-216-801-11 METAL CHIP 22 5% 1/10W
R6926 1-216-801-11 METAL CHIP 22 5% 1/10W
R6931 1-216-864-11 SHORT CHIP
R6932 1-216-864-11 SHORT CHIP
R6935 1-216-864-11 SHORT CHIP
R6936 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6990 1-216-864-11 SHORT CHIP
R6991 1-216-864-11 SHORT CHIP
R6992 1-216-864-11 SHORT CHIP
R7000 1-216-864-11 SHORT CHIP
R7002 1-216-864-11 SHORT CHIP
R7004 1-216-864-11 SHORT CHIP
R7006 1-216-864-11 SHORT CHIP
R7007 1-216-864-11 SHORT CHIP
R7008 1-216-864-11 SHORT CHIP
R7021 1-216-864-11 SHORT CHIP
R7022 1-216-864-11 SHORT CHIP
RELAY
!
RY6001 1-755-388-11 RELAY (AC POWER)
!
RY6002 1-755-388-11 RELAY (AC POWER)
SPARK GAP
!
SG6000 1-576-487-21 ELEMENT, SPARK
TRANSFORMER
!
T6000 1-443-970-21 CONVERTER TRANSFORMER (PIT)
!
T6500 1-443-971-11 TRANSFORMER (STANDBY)
VARISTOR
!
VD6001 1-804-991-21 VARISTOR
!
VD6003 1-804-991-21 VARISTOR
!
VD6004 1-804-992-21 VARISTOR
HA
A-1177-119-A HA BOARD, MOUNTED
CAPACITOR
C100 1-100-597-91 CERAMIC CHIP 0.1µF 10% 25V
CONNECTOR
* CN100 1-820-297-11 HEADER ASSEMBLY (PRINT PWB)
RESISTOR
R100 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R101 1-218-839-11 METAL CHIP 470 0.50% 1/10W
R102 1-218-846-11 METAL CHIP 910 0.50% 1/10W
R103 1-218-853-11 METAL CHIP 1.8K 0.50% 1/10W
R104 1-218-861-11 METAL CHIP 3.9K 0.50% 1/10W
SWITCH
S100 1-692-431-21 SWITCH, TACTILE
S101 1-692-431-21 SWITCH, TACTILE
S102 1-692-431-21 SWITCH, TACTILE
S103 1-692-431-21 SWITCH, TACTILE
S104 1-692-431-21 SWITCH, TACTILE
S105 1-692-431-21 SWITCH, TACTILE
HB
A-1177-120-A HB BOARD, MOUNTED
CAPACITOR
C110 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C111 1-128-991-21 ELECT CHIP 10µF 20% 50V
C112 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C113 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C114 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C115 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C116 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C117 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C118 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C119 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C120 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C121 1-162-974-11 CERAMIC CHIP 0.01µF 50V
CONNECTOR
* CN110 1-820-292-11 HEADER ASSEMBLY (PRINT PWB) 13P
DIODE
D113 6-500-861-01 DIODE SML-020MVT-T86
GHAHB
