3-5. SEMICONDUCTORS
LM75BIM-5/NOPB
M24C02-WMN6T(B)
1
TOP VIEW
8 PINS
MCZ3001DB
1
TOP VIEW
18 PINS
MM1431ATT
NJM2870F18 (TE2)
XXC6219B182MR
1
5 PINS
NJM2387DL2-TE1
1
5
PQ1CG2032FZ
5
1
2
3
4
PQ30RV11
1
4
RPM7240-H8
1 2 3
2SC1623-L5L6
UPA1716G
E
B
C
10ERB20-TB3
UF4005/23
CATHODE
ANODE
1SS184
1
1
2
2
3
3
D10SC4M-F
D10SC6M-4012
1
2
3
1
2
3
D2L20U-TA
RD8.2ES-B2
CATHODE
ANODE
D2SB60A-F04
D2SB60L
D4SBL40
D4SBS6-F
+
~
~
–
+
~
~
–
D5LC20U-4012
MARKING SIDE VIEW
CATHODE
ANODE
DTZ10B
HZU5.6GTRF
MA111-TX
UDZS-TE17-5.6B
CATHODE
ANODE
ERA22-08TP3
CATHODE
ANODE
P6SMB39AT3
S3G
ANODE
CATHODE
SML-020MVT-T86
Cathode mark
Green
Red
1
1
2
2
4
4
3
3
SML-210MT-T86
SML-210VTT86
SML-310LTT86
CATHODE MARK
