Sony KDF-46E2000 - S2 Board Schematic Diagram

KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
83
            






S2 BOARD SCHEMATIC DIAGRAM
C160
1608
25V
0.1
F
C162
1608
50V
10p
CH
C161
1608
10V
1
B
C163
1608
50V
10p
CH
1/10W
RN-CP
5%
22
R161
R166
CHIP
0
R167
0
1/10W
RN-CP
5%
22
R162
1
2
3
4
5
5P
CN160
SET_5V
GND
SDA_TV
SCL_TV
GND
R165
RN-CP
10k
8765
4321
LM75BIM-5/NOPB
IC160
S2
Lamp temp detection
9-883-709-01<LA4>S2
TO G BOARD
CN6804
