Sony KDF-46E2000 - Page 131

131
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
D8424 8-719-977-28 DIODE DTZ10B
D8425 8-719-069-55 DIODE UDZSTE-175.6B
D8426 8-719-977-28 DIODE DTZ10B
D8427 8-719-977-28 DIODE DTZ10B
D8428 8-719-083-57 DIODE UDZSTE-173.6B
D8429 8-719-083-57 DIODE UDZSTE-173.6B
IC
IC8402 8-753-232-63 IC CXA2229Q-T6
IC8403 8-752-107-98 IC CXA2188Q-T4
IC8404 8-759-278-58 IC NJM4558V-TE2
JACK
J8400 1-780-271-11 S CONNECTOR BLOCK
J8401 1-819-357-11 PHONO JACK 10P
* J8402 1-819-358-11 PHONO JACK
* J8403 1-819-358-11 PHONO JACK
COIL
L8401 1-469-555-21 INDUCTOR 10µH
L8402 1-469-555-21 INDUCTOR 10µH
L8403 1-469-555-21 INDUCTOR 10µH
L8404 1-469-555-21 INDUCTOR 10µH
L8405 1-469-555-21 INDUCTOR 10µH
L8406 1-469-555-21 INDUCTOR 10µH
TRANSISTOR
Q8400 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8402 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8403 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8405 6-551-390-01 TRANSISTOR RT1A3906-T122-1
Q8406 6-551-390-01 TRANSISTOR RT1A3906-T122-1
Q8407 6-551-390-01 TRANSISTOR RT1A3906-T122-1
Q8408 8-729-600-22 TRANSISTOR 2SA1235-F
Q8409 8-729-600-22 TRANSISTOR 2SA1235-F
Q8410 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8411 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8412 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8413 8-729-600-22 TRANSISTOR 2SA1235-F
Q8414 8-729-600-22 TRANSISTOR 2SA1235-F
Q8607 8-729-600-22 TRANSISTOR 2SA1235-F
RESISTOR
R8401 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R8402 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R8404 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R8405 1-216-809-11 METAL CHIP 100 5% 1/10W
R8406 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R8407 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8409 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R8410 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R8411 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R8412 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R8413 1-216-853-11 METAL CHIP 470K 5% 1/10W
R8414 1-216-809-11 METAL CHIP 100 5% 1/10W
R8415 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R8416 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8417 1-216-809-11 METAL CHIP 100 5% 1/10W
R8420 1-216-809-11 METAL CHIP 100 5% 1/10W
R8422 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R8424 1-216-809-11 METAL CHIP 100 5% 1/10W
R8425 1-216-809-11 METAL CHIP 100 5% 1/10W
R8427 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8428 1-216-815-11 METAL CHIP 330 5% 1/10W
R8429 1-216-809-11 METAL CHIP 100 5% 1/10W
R8430 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R8431 1-216-815-11 METAL CHIP 330 5% 1/10W
R8432 1-216-807-11 METAL CHIP 68 5% 1/10W
R8433 1-216-807-11 METAL CHIP 68 5% 1/10W
R8434 1-216-809-11 METAL CHIP 100 5% 1/10W
R8435 1-216-809-11 METAL CHIP 100 5% 1/10W
R8436 1-216-864-11 SHORT CHIP
R8437 1-216-864-11 SHORT CHIP
R8442 1-216-864-11 SHORT CHIP
R8443 1-216-864-11 SHORT CHIP
R8456 1-216-864-11 SHORT CHIP
R8457 1-216-864-11 SHORT CHIP
R8464 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8465 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8466 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8467 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8468 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8469 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8470 1-216-853-11 METAL CHIP 470K 5% 1/10W
R8471 1-216-853-11 METAL CHIP 470K 5% 1/10W
U
