Speaker Bracket must be secured following the above Screw
Order.
On “Left” Speaker Secure Speaker
wire as shown below using
265206401 TAPE, HIMELON (20X40)
Note:
PCN MB607734 Shows different Tape position
please disregard that location and use above
SPEAKER WIRE DRESSING (CONTINUED)
To Next Page
